| Ref | Part Number | Description |
|---|
| 1 |
539107354 |
BODY W/DECALS This part replaces 539106762. Price: $349.99 |
| 1 |
93-7836 |
DECAL-PEDAL, TRACTION This part replaces 27-7320. Price: $14.38 |
| 2 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 2 |
70-2200 |
DECAL This part replaces 63-3280. Price: $5.09 |
| 3 |
13-5609 |
DISCONTINUED This part replaces 72-3630. Price: Call Us |
| 3 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 4 |
21-2770 |
PAD-FLOOR PLATE, RH Price: $96.81 |
| 4 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 5 |
539106847 |
BUSHING RAKE Price: $6.99 |
| 5 |
66-6390 |
DECAL-CAUTION Price: $27.63 |
| 6 |
21-2660-01 |
PLATE-SIDE This part replaces 21-2660. Price: $299.86 |
| 6 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 7 |
32128-21 |
NUT-HF Price: $0.39 |
| 7 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 8 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 8 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 9 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 10 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 10 |
72-3690 |
DISCONTINUED Price: Call Us |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 11 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 12 |
27-7290 |
DECAL-PTO Price: $17.38 |
| 12 |
539100488 |
BEARING, FLANGED Price: $39.99 |
| 13 |
3290-144 |
SCREW-SHWH Price: $0.47 |
| 13 |
539100439 |
BELT, DRIVE RAKE/SLICER DFS Price: $29.99 |
| 14 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 14 |
539106805 |
LINKAGE Price: $5.99 |
| 15 |
540075051 |
WHEEL 8 X 1 3/4 RAKE Price: $27.99 |
| 16 |
24-6390 |
STUD-HOLDDOWN, BATTERY Price: $19.83 |
| 16 |
531350601 |
PULLEY IDLER, BACKSIDE 3 INCH This part replaces 539110311. Price: $19.99 |
| 17 |
32103-2 |
NUT-WING Price: $0.68 |
| 17 |
539106643 |
REAR FLAP Price: $22.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
539106759 |
FRONT AXLE Price: $119.99 |
| 19 |
28-1280 |
DISCONTINUED Price: Call Us |
| 19 |
539108541 |
PULLEY W/SET SCREW Price: $129.99 |
| 20 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 20 |
70-1180 |
DISCONTINUED Price: Call Us |
| 21 |
24-6420-03 |
HOLDDOWN-BATTERY This part replaces 24-6420. Price: $55.90 |
| 21 |
539100482 |
BEARING, ONLITE RAKE/DT Price: $8.99 |
| 22 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 22 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 23 |
2412-61 |
TINNERMAN CLIP Price: $4.93 |
| 23 |
539106672 |
FLAP ROD Price: $12.99 |
| 24 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 24 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 25 |
2412-4 |
CLAMP-R Price: $4.22 |
| 25 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 26 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 26 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 27 |
37-9650 |
TRIM-BOX, TOOL Price: $19.76 |
| 27 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 28 |
539106754 |
SHAFT GUARD Price: $19.99 |
| 28 |
67-1710 |
DECAL-WARNING Price: $7.83 |
| 29 |
539108070 |
BELT SHIELD POWER RAKE This part replaces 539108069. Price: $119.99 |
| 29 |
71-4860 |
DECAL Price: $16.67 |
| 30 |
38-4550-03 |
COVER-INSTRUMENTS This part replaces 38-4550. Price: $448.71 |
| 30 |
539106816 |
SLIDER Price: $44.99 |
| 31 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 31 |
92-7802 |
DECAL-INSTR., START This part replaces 43-4290. Price: $22.12 |
| 32 |
539000035 |
KNOB This part replaces 540000035. Price: $19.99 |
| 32 |
92-7800 |
BATTERY COVER ASM This part replaces 24-9740. Price: $65.49 |
| 33 |
39-8020 |
TRIM-COVER, INSTRUMENT Price: $15.23 |
| 33 |
539030485 |
KNOB This part replaces 540030485. Price: $6.99 |
| 34 |
49-2280 |
DECAL Price: $22.38 |
| 34 |
539108588 |
STUD 1/2-13 4-3/4 ZD This part replaces 540052761. Price: $4.99 |
| 35 |
43-4300 |
TRIM-FRAME, REAR Price: $13.54 |
| 35 |
539102827 |
SPACER Price: $4.99 |
| 36 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 36 |
596433401 |
Nuts This part replaces 539990625. Price: $2.99 |
| 37 |
522795001 |
IDLER, ARM, BLACK This part replaces 539108067. Price: $60.99 |
| 37 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 38 |
2412-74 |
R-CLAMP Price: $2.37 |
| 38 |
539106849 |
CABLE POWER RAKE Price: $27.99 |
| 39 |
32128-20 |
NUT-HF Price: $0.99 |
| 39 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 40 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 40 |
539910061 |
KEY, 3/16 SQUARE This part replaces 540005226. Price: $3.99 |
| 41 |
32128-33 |
NUT-HF Price: $0.25 |
| 41 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 42 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 42 |
93-3183 |
TOOL BOX ASM This part replaces 38-4530. Price: $240.67 |
| 43 |
539106772 |
BACKING PLATE ORANGE Price: $89.99 |
| 43 |
72-3560 |
DECAL Price: $12.52 |
| 44 |
540000058 |
WHEEL 10 X 1 3/4 Price: $60.99 |
| 44 |
93-7830 |
DECAL-TORQUE This part replaces 67-1720. Price: $23.91 |
| 45 |
540053401 |
WHEEL 10 X 1 3/4 Price: $54.99 |
| 45 |
68-8610-01 |
EXTENSION-FENDER This part replaces 68-8610. Price: $186.20 |
| 46 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 46 |
539106663 |
AXLE, REAR Price: $49.99 |
| 47 |
12-3270 |
SCREW Price: $3.09 |
| 47 |
539109273 |
PIN ROLL 1/4 X 1-1/8 This part replaces 540000364. Price: $2.99 |
| 48 |
21-2760 |
PAD-PLATE FLOOR, LH Price: $96.42 |
| 48 |
540009127 |
BEARING This part replaces 540000319. Price: $30.99 |
| 49 |
539000485 |
FLANGE BEARING ZINC PLATED This part replaces 540000321. Price: $3.99 |
| 49 |
88-0070-01 |
PLATE-FLOOR This part replaces 23-5220. Price: $169.68 |
| 50 |
539976982 |
WASHER 5/8 FLAT This part replaces 539000436. Price: $3.99 |
| 50 |
72-3700 |
DECAL-DANGER Price: $38.02 |
| 51 |
539106757 |
REAR COVER ORANGE Price: $49.99 |
| 52 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 53 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 54 |
539108543 |
ENGINE PULLEY W/SET SCW Price: $32.99 |
| 55 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 56 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 57 |
539108022 |
DEPTH SHIM Price: $11.99 |
| 58 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 59 |
539990297 |
COTTER PIN Price: $2.99 |
