| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 2 |
725533355 |
SCREW MC6S 5X25 Price: $3.99 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
584288701 |
VALVE This part replaces 537294401. Price: $29.99 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
537207101 |
PLUG Price: $6.99 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
503552201 |
CYLINDER PLUG Price: $6.99 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 6 |
503235111 |
SPARK PLUG M14X1.25 NGK BPMR7A Price: $4.99 |
| 7 |
537208001 |
GASKET Price: $5.99 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
537401501 |
PISTON RING This part replaces 503289046. Price: $12.99 |
| 9 |
22-8500 |
O-RING Price: $18.87 |
| 9 |
537254702 |
PISTON 49 MM Price: $109.99 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 10 |
577572401 |
NEEDLE BEARING PISTON PIN 12X1 This part replaces 503255601. Price: $11.99 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
737431200 |
WRIST PIN CLIP Price: $3.99 |
| 12 |
23-3030 |
SPACER Price: $33.93 |
| 13 |
22-8480 |
RING-SNAP Price: $49.87 |
