| Ref | Part Number | Description |
|---|
| 1 |
110-1381-03 |
BROOM MOUNT ASM Price: $411.68 |
| 2 |
112-1401 |
RH WING ASM Price: $181.30 |
| 3 |
112-1402 |
LH WING ASM Price: $181.30 |
| 4 |
105-9602 |
BRUSH Price: $123.93 |
| 5 |
105-9625-03 |
WEIGHT-BRUSH Price: $32.69 |
| 11 |
3256-80 |
WASHER-PLAIN Price: $0.25 |
| 13 |
710125 |
SPACER Price: $12.99 |
| 14 |
32151-48 |
E-RING Price: $1.41 |
| 15 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
5-2942 |
SHACKLE Price: $16.99 |
| 18 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 19 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
322-13 |
SCREW-HH Price: $2.73 |
| 24 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 39 |
138-2133-03 |
WEIGHT-REEL This part replaces 104-0534-03. Price: $123.72 |
| 40 |
323-19 |
SCREW-HH Price: $1.70 |
| 41 |
75-5270 |
SPACER-KNOB, SEAT This part replaces 99-2058. Price: $4.61 |
| 43 |
323-7 |
SCREW-HH Price: $0.65 |
