| Ref | Part Number | Description |
|---|
| 9 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 10 |
1100044 |
Hex Head Screw, 5/16-18 x 3/4 Price: $3.76 |
| 13 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 1733398. Price: $3.90 |
| 21 |
712-0324 |
Hex Ins. L-Nut 1/4-20 Thd. This part replaces 1817146. Price: $3.38 |
| 26 |
1752556 |
BEARING-FL Not Available Price: |
| 29 |
716-0106 |
E-ring This part replaces 1177567. Price: $3.52 |
| 39 |
1721492 |
SPRING Not Available Price: |
| 43 |
1185689 |
RETAINING RING EXT Not Available Price: |
| 73 |
1773025 |
Pivot Arm Assembly Price: Call Us |
| 75 |
1770696 |
Pivot Block Price: Call Us |
| 85 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces 1107383. Price: $3.90 |
| 119 |
1185816 |
Flat Washer 1-1/64 Price: $3.15 |
| 131 |
710-0946 |
SCREW 1/4-20 X .625 This part replaces 1772882. Price: $3.24 |
| 163 |
712-3017 |
HEX NUT 3/8-16 GR5 This part replaces 1186231. Price: $3.90 |
| 165 |
1715716 |
Nyliner Bushing Not Available Price: |
| 166 |
1720883 |
WASHER Not Available Price: |
| 180 |
736-0326 |
Flat Washer,.510 x 1.00 This part replaces 1107385. Price: $3.89 |
| 182 |
714-0115 |
Pin, Cotter, 1/8 x 1.00 This part replaces 1100350. Price: $3.48 |
| 186 |
1771081 |
Actuator Harness Price: $3.05 |
| 188 |
1771668 |
SWITCH ROC Not Available Price: |
| 197 |
1773104 |
LABEL-LIFT Not Available Price: |
| 227 |
714-0474 |
Cotter Pin This part replaces 1100349. Price: $4.08 |
| 231 |
710-0521 |
SCREW 3/8-16 x 3 GR8 This part replaces 1111614. Price: $4.54 |
| 232 |
710-0192 |
Scr. Tr. Mach. #10-24 x 0.380" This part replaces 1773610. Price: $3.08 |
| 234 |
1185376 |
PIN-DRIVE Not Available Price: |
| 235 |
1817091 |
HITCH PIN Not Available Price: |
| 236 |
710-04043 |
SCREW 5/16-18 This part replaces 1186329. Price: $3.96 |
| 237 |
915-0249 |
Roll Pin This part replaces 1187961. Price: $5.94 |
| 239 |
1766259 |
COLLAR-HEI Not Available Price: |
| 240 |
1766257 |
BLOCK-HEIG Not Available Price: |
| 241 |
1738490 |
FLAT WASHER SPECIA Not Available Price: |
| 242 |
736-0227 |
WASHER:FLAT: .390 x 1.50 x .134 This part replaces 1763355. Price: $5.78 |
| 244 |
1773201 |
INDICATOR-HEIGHT Not Available Price: |
| 246 |
1765485 |
KNOB-HEIGHT ADJUST Not Available Price: |
| 247 |
1773206 |
EXTENSION SPRING Not Available Price: |
| 248 |
1773183 |
CABLE ASSEMBLY Not Available Price: |
| 249 |
1773133 |
SCREW-HT A Not Available Price: |
| 250 |
1772806 |
CLAMP-LIFT Not Available Price: |
| 251 |
1772866 |
Lift Rod Price: Call Us |
| 252 |
1772438 |
SWIVEL-REA Not Available Price: |
| 254 |
1766080 |
SPACER Not Available Price: |
| 258 |
1772970001 |
Lift Assembly Price: Call Us |
| 262 |
1766346 |
GROMMET Not Available Price: |
| 277 |
1185958 |
Keps Nut,10-24 Price: Call Us |
| 285 |
1773064 |
Cover Price: Call Us |
| 339 |
1706621 |
CLEVIS PIN .5X2.75 Not Available Price: |
| 355 |
1770688001 |
SUPPORT FRONT (BLACK) Not Available Price: |
| 356 |
1771799001 |
Rear Support Price: Call Us |
| 380 |
1770694 |
Spacer Price: Call Us |
| 385 |
1771678 |
Actuator Price: Call Us |
| 393 |
1772978 |
Lift Rod Price: Call Us |
