| Ref | Part Number | Description |
|---|
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $69.99 |
| 2 |
911-3149A |
Cam Follower This part replaces 711-3149. Price: $39.63 |
| 3 |
596270601 |
Levers This part replaces 532195230. Price: $19.99 |
| 3 |
712-3062 |
HEX JAM NUT 9/16-1 Not Available Price: |
| 4 |
712-3063 |
Nut, Hex Crown Lock, 5/8-18 Price: $7.26 |
| 5 |
703-1082 |
STEERING ARM Not Available Price: |
| 6 |
703-1031 |
SEAL RETAINER Not Available Price: |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 7 |
923-3039 |
Seal This part replaces 723-3039. Price: $7.77 |
| 9 |
748-3008 |
BUSHING Not Available Price: |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
941-3023 |
COLUMN BEARING This part replaces 741-3023. Price: $7.17 |
| 11 |
711-3208 |
PIVOT SHAFT Not Available Price: |
| 12 |
736-3029 |
Washer, Flat, .781 X 1.25 X .027 Thk Price: $10.30 |
| 13 |
737-3001 |
Fitting, Lube, 45 Deg 1/4-28 Taper Price: $10.74 |
| 14 |
903-1029 |
BEARING CUP Not Available This part replaces 703-1029. Price: |
| 15 |
941-3021 |
RETAINER/BALL ASSEMBLY This part replaces 741-3021. Price: $32.76 |
| 16 |
703-1793 |
SHAFT ASSEMBLY- Not Available Price: |
| 17 |
719-3053 |
ADJUSTING PLUG Not Available Price: |
| 18 |
714-0474 |
Pin, Cotter, 1/8 Dia X .75 Lg Price: $4.08 |
| 19 |
923-3015 |
BALL JOINT Not Available This part replaces 723-3015. Price: |
| 20 |
712-3029 |
Nut, Hex Jam, 1/2-20 GR5 Price: $6.01 |
| 21 |
747-3140 |
DRAG LINK Not Available Price: |
| 22 |
912-3001 |
Nut, Jam, 3/8-24 This part replaces 712-3001. Price: $5.94 |
| 23 |
923-3000 |
JOINT-BALL-3/8-24 This part replaces 723-3000. Price: $18.68 |
| 24 |
912-3002 |
HEX NUT CASTLE This part replaces 712-3002. Price: $6.01 |
| 25 |
714-0507 |
Pin, Cotter, 3/32 Dia X .75 Lg Price: $3.93 |
| 26 |
703-1817 |
STEERING SUPPORT PLATE Not Available Price: |
| 27 |
747-3016 |
CLAMP Not Available Price: |
| 28 |
712-0237 |
Nut, Hex Center Lock, 5/16-24 Price: $4.37 |
| 29 |
710-1260A |
Self Tapping Screw, 5/16-18 x .75 This part replaces 710-3004. Price: $3.34 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532195301 |
SPRINGS This part replaces 532195304. Price: $11.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464808 |
LINK ASSY LIFT.REAR LINK.ASM.P This part replaces 532197984. Price: $12.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
