| Ref | Part Number | Description |
|---|
| 1 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 1 |
532439997 |
WHEEL.STEERING.HUSQ.PREM.HRDRM Price: $49.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
8-0280 |
DISCONTINUED Price: Call Us |
| 3 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 4 |
51-0850-01 |
SUPPORT-PULLEY This part replaces 51-0850. Price: $306.47 |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 6 |
47-3930-01 |
LOCKUP BRACKET ASM This part replaces 47-3930. Price: $270.92 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
47-3640-01 |
CYLINDER REST ASM This part replaces 47-3640. Price: $44.42 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3290-216 |
WASHER Price: $3.83 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
325-6 |
SCREW-HH Price: $1.42 |
| 11 |
47-3870-01 |
RH CHANNEL ASM This part replaces 47-3870. Price: $235.39 |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
237-79 |
O-RING Price: $5.46 |
| 15 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
115-4949-01 |
HYDRAULIC CYLINDER ASM (14.00 STROKE) This part replaces 47-3720. Price: $1,376.05 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
20-4390 |
SPACER Price: $12.54 |
| 18 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 19 |
42-3550-01 |
COVER-MOUNT, CYLINDER This part replaces 42-3550. Price: $108.41 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
3-0144 |
SHAFT Price: $53.89 |
| 21 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
47-3860-01 |
LH CHANNEL ASM This part replaces 47-3860. Price: $215.68 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 25 |
47-3010-01 |
TRAILER ASM This part replaces 47-3010. Price: $3,956.22 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 28 |
60-9110-01 |
LIFT BAIL PIN ASM This part replaces 60-9110. Price: $84.41 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
47-3230-01 |
NO. 1 LIFT ARM ASM This part replaces 47-3230. Price: $907.15 |
| 32 |
32513-5 |
Nut-Lock Price: Call Us |
| 33 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
| 37 |
325-7 |
SCREW-HH Price: $1.53 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
