| Ref | Part Number | Description |
|---|
| 1 |
603000006 |
FILTER, OIL Price: $17.99 |
| 1 |
98-9575 |
WATER PUMP ASM Price: $347.70 |
| 2 |
603000869 |
SCREW-M8 X 1.25 30, TRI, HX F Price: $1.99 |
| 2 |
710-0573 |
Screw, Hex Cap Lock, 5/16-18 x 1.25 GR5 Price: $5.53 |
| 2 |
98-9582 |
FLANGE-PUMP, WATER Price: $39.58 |
| 3 |
603000885 |
REGULATOR, VOLTAGE, GX620 Price: $899.99 |
| 3 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 3 |
98-9583 |
BEARING Price: $110.11 |
| 4 |
100-1932 |
PIPE-RETURN, WATER This part replaces 98-9577. Price: $8.45 |
| 4 |
603000911 |
BRACKET, OIL FILTER MOUNT Price: $22.99 |
| 4 |
711-1339 |
MOTOR SHAFT Not Available Price: |
| 5 |
603001015 |
ADAPTER, 90-5 ORB, 5/16 TUBE Price: $17.99 |
| 5 |
911-04345 |
PINION SHAFT 16T Not Available This part replaces 711-1344. Price: |
| 5 |
98-9576 |
MECHANICAL SEAL ASM Price: $27.04 |
| 6 |
603001056 |
HOSE, 3/8 REMOTE OIL, HONDA Price: $49.99 |
| 6 |
98-9581 |
IMPELLER-PUMP, WATER Price: $38.74 |
| 7 |
603001057 |
CLAMP, HOSE #4 Price: $2.99 |
| 7 |
711-1397 |
SHAFT-2 SPD ACTUAT Not Available Price: |
| 7 |
98-9632 |
GASKET-PUMP, WATER Price: $7.25 |
| 8 |
603001099 |
ADAPTER, 90-6 ORB, 3/8 TUBE Price: $17.99 |
| 8 |
715-0159 |
SPRING PIN Not Available Price: |
| 8 |
98-9353 |
BOLT Price: $0.76 |
| 9 |
603001100 |
HOSE, 5/16, REMOTE OIL, HONDA Price: $49.99 |
| 9 |
716-0185 |
Ring, Retaining Price: $3.22 |
| 9 |
98-9357 |
BOLT Price: $2.46 |
| 10 |
603001142 |
NIPPLE, M20, REMOTE OIL Price: $24.99 |
| 10 |
716-0384 |
Ring, Retaining Price: $3.74 |
| 10 |
98-9717 |
CLAMP Price: $8.41 |
| 11 |
603001168 |
O-RING 11.8 X 2.4 Price: $1.99 |
| 11 |
716-0387 |
RETAINING RING Not Available Price: |
| 11 |
98-9574 |
PIPE-WATER Price: $17.67 |
| 12 |
603001308 |
LOCK NUT, FLG M8 X 1.25 NYLON Price: $3.99 |
| 12 |
716-0393 |
RETAINING RING Not Available Price: |
| 13 |
603001587 |
SCREW, M6 X 1 X 25 THD FORM Price: $3.99 |
| 13 |
716-0396 |
ROTOR CLIP Not Available Price: |
| 14 |
603001667 |
PLATE, FUEL/OIL SYSTEM Price: $179.99 |
| 14 |
717-3472 |
DRIVE GEAR 24T/17T Not Available Price: |
| 15 |
603001682 |
ADAPTER, ORS -6, 3/8 HOSE, ST Price: $19.99 |
| 15 |
717-3473 |
DRIVE GEAR 33T/17T Not Available Price: |
| 16 |
603001683 |
ADAPTER, ORS -5, 5/16 HOSE, ST Price: $19.99 |
| 16 |
717-3480 |
DRIVE GEAR 59T/50T Not Available Price: |
| 17 |
603000910 |
ADAPTER, OIL FILER, ENG HONDA Price: $6.99 |
| 17 |
717-3484 |
OVERRUNNING CLUTCH Not Available Price: |
| 18 |
718-0674 |
FRONT COVER Not Available Price: |
| 19 |
718-0678 |
DRIVE SPACER Not Available Price: |
| 20 |
718-3116 |
Collar, 2 Speed Price: $77.88 |
| 21 |
721-0496 |
Seal, Oil Price: $9.52 |
| 22 |
721-0501 |
O-RING 2.987 x .103 Not Available Price: |
| 23 |
721-0507 |
OIL SEAL Not Available Price: |
| 24 |
932-05125 |
DETENT SHAFT SPRING This part replaces 732-0863. Price: $3.66 |
| 25 |
736-0715 |
THRUST WASHER Not Available Price: |
| 26 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 27 |
741-1106 |
BALL BEARING Not Available Price: |
| 28 |
741-1107 |
BALL BEARING Not Available Price: |
| 29 |
741-1109 |
ANGULAR CONTACT BEARING Not Available Price: |
| 30 |
741-1112 |
THRUST BEARING Not Available Price: |
| 31 |
941-3037 |
Bearing, Ball This part replaces 741-3037. Price: $38.73 |
| 32 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 33 |
741-3118 |
Bearing, Sleeve Price: $23.07 |
