| Ref | Part Number | Description |
|---|
| 1 |
132-8160 |
PIN ASM This part replaces 108-5181. Price: $165.32 |
| 2 |
108-9870 |
PIN-COUPLER Price: $125.84 |
| 3 |
112-9587 |
RH PEDAL ASM Price: $231.64 |
| 4 |
112-9588 |
LH PEDAL ASM Price: $231.64 |
| 5 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 6 |
108-5178 |
EAR-PIVOT Price: $31.75 |
| 7 |
110-3510 |
NUT-RETAINER Price: $5.77 |
| 8 |
107-2604 |
SHAFT Price: $168.99 |
| 9 |
32151-29 |
RING-RETAINING Price: $3.59 |
| 10 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 11 |
107-7851 |
BEARING-FLANGE, 2 BOLT Price: $62.42 |
| 12 |
3234-15 |
SCREW-HHF Price: $1.97 |
| 13 |
98-2654 |
PIN-PIVOT Price: $77.85 |
| 14 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 15 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 16 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 17 |
110-9785 |
PLATE-RETAINER V Price: $162.24 |
| 18 |
112-9556 |
FLOORMAT-PLATFORM Price: $172.36 |
| 19 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 20 |
108-9866-03 |
PLATE-COVER Price: $75.24 |
| 21 |
32148-7 |
NUT-CLINCH Price: $0.98 |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 23 |
112-9555 |
PANEL-ACCESS, FLOOR Price: $69.78 |
| 24 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
