| Ref | Part Number | Description |
|---|
| 1 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
71-3500 |
DISCONTINUED Price: Call Us |
| 3 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 4 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 4 |
538691101 |
SPINDLE.WLDMT.LH.16IN.TEX.X431 This part replaces 532403089. Price: $19.99 |
| 5 |
538691001 |
SPINDLE.WLDMT.RH.16IN.TEX.X431 This part replaces 532403090. Price: $19.99 |
| 5 |
66-2670 |
BRACKET-THROTTLE Price: $8.98 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
32128-33 |
NUT-HF Price: $0.25 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
94-6968 |
BRACKET-BELLCRANK, THROTTLE Price: $27.54 |
| 11 |
95-6270-03 |
BRACKET-MOUNT, ENGINE This part replaces 95-6270. Price: $107.07 |
| 12 |
94-9426 |
CABLE-THROTTLE Price: $30.65 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
95-6272-03 |
BRACKET-ENGINE MOUNT This part replaces 95-6272. Price: $131.75 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
95-1592-03 |
BRACKET-BASE, BATTERY This part replaces 95-1592. Price: $34.16 |
| 16 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 18 |
323-9 |
SCREW-HH Price: $1.29 |
| 19 |
28-1280 |
DISCONTINUED Price: Call Us |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
95-4410-01 |
CABLE - BATTERY,POSITIVE This part replaces 95-4410. Price: $100.58 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
63-7340 |
DISCONTINUED Price: Call Us |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 24 |
94-7343 |
BASE-BATTERY Price: $118.61 |
| 25 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 26 |
95-1599-03 |
BRACKET-BASE, BATTERY This part replaces 95-1599. Price: $36.74 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
98-3883 |
CLAMP-WIRE Price: $0.81 |
| 29 |
32128-20 |
NUT-HF Price: $0.99 |
| 30 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 31 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 32 |
63-7140 |
MOUNT-SHOCK, ENGINE Price: $54.67 |
| 34 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 36 |
3256-40 |
WASHER-FLAT Price: $2.10 |
| 37 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 38 |
3213-2 |
SCREW-HH Price: $1.90 |
| 40 |
323-11 |
SCREW-HH Price: $1.08 |
| 41 |
2412-58 |
CLAMP Price: $5.78 |
| 42 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 47 |
3256-51 |
WASHER-FLAT Price: $0.19 |
| 48 |
94-9420 |
LINK-THROTTLE Price: $34.56 |
| 49 |
94-9421 |
BELLCRANK-THROTTLE Price: $15.33 |
| 50 |
94-9422 |
SCREW-SHOULDER Price: $1.93 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
321-4 |
SCREW-HH Price: $0.99 |
| 53 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
322-6 |
SCREW-HH Price: $0.45 |
| 55 |
63-7141 |
MOUNT-SHOCK, ENGINE Price: $61.74 |
| 56 |
80-7730 |
SPACER Price: $1.97 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
