| Ref | Part Number | Description |
|---|
| 1 |
32104-60 |
SCREW-HWH Price: $0.68 |
| 1 |
3269-32 |
RIVET-POP Price: $0.25 |
| 2 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 3 |
80-9240 |
PANEL-CONTROL Price: $31.64 |
| 3 |
83-6090 |
DECAL-AERATE/LIFT,TILL Price: $19.83 |
| 3 |
93-9368 |
PANEL-CONTROL DECAL Price: $8.35 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 5 |
80-9290 |
BUTTON-GREEN, SWITCH Price: $256.99 |
| 6 |
14-5199 |
PANEL-CONTROL, TILLER Price: $78.82 |
| 7 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 8 |
80-9280 |
SWITCH Price: $62.38 |
| 9 |
80-9270 |
BRACKET-MOUNT, SWITCH Price: $42.47 |
| 11 |
80-7790 |
BRACKET-BUZZER Price: $8.78 |
| 12 |
80-9330 |
AUDIO ALARM ASM Price: $137.61 |
| 13 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 14 |
80-7190 |
SHAFT-PIVOT Price: $10.20 |
| 15 |
32121-79 |
PIN-ROLL Price: $10.59 |
| 16 |
80-7110 |
HANDLE Price: $164.73 |
| 17 |
323-29 |
SCREW-HH Price: $0.42 |
| 18 |
80-7200 |
SPACER-BRAKE Price: $15.40 |
| 19 |
256-206 |
BUSHING Price: $1.15 |
| 20 |
65-8970 |
KNOB-SHIFT Price: $18.47 |
| 21 |
86-8420 |
LEVER-BRAKE Price: $112.71 |
| 22 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 24 |
80-9740 |
CABLE-BRAKE Price: $82.97 |
| 25 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 26 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 27 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 28 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 29 |
240-12 |
GROMMET Price: $28.58 |
| 30 |
86-8510 |
HANDLE ASM Price: $520.35 |
| 31 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 32 |
80-8680 |
STUD Price: $17.33 |
| 33 |
80-6900 |
SUPPORT-SWITCH Price: $11.99 |
| 34 |
40-8200 |
SWITCH-MICRO Price: $29.35 |
| 35 |
3290-313 |
SCREW-SPH Price: $6.09 |
| 36 |
2412-94 |
CLAMP Price: $2.31 |
| 37 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 38 |
80-7220 |
CABLE-CONTROL, STROKE Price: $329.40 |
| 39 |
3220-1 |
NUT-JAM Price: $0.99 |
| 40 |
80-7080 |
HOUSING Price: $261.02 |
| 41 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 42 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 43 |
80-7150 |
SPRING-COMPRESSION Price: $19.96 |
| 44 |
80-7230 |
HUB-OVERRIDE Price: $75.32 |
| 45 |
80-7060 |
SHAFT-OVERRIDE Price: $174.71 |
| 46 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 47 |
2412-120 |
CLAMP-R Price: $6.49 |
| 48 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 49 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 50 |
86-8450-03 |
COVER-HANDLE, LOWER This part replaces 86-8450. Price: $58.58 |
| 51 |
80-7160 |
ARM-TRACTION Price: $91.54 |
| 52 |
71-4170 |
SWITCH Price: $166.36 |
| 53 |
3250-35 |
SCREW-PPH Price: $3.24 |
| 54 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 55 |
3217-16 |
NUT-HEX Price: $0.25 |
| 56 |
108-1317 |
DECAL-WARNING This part replaces 80-8020. Price: $49.49 |
| 56 |
83-6060 |
DECAL-OPERATION, TILLER Price: $22.40 |
| 56 |
93-9369 |
DECAL - WARNING Price: $22.96 |
| 57 |
80-9300 |
BUTTON-RED, SWITCH Price: $269.65 |
| 58 |
80-8070 |
DECAL-CONTROL, PARKING BRAKE Price: $8.01 |
| 58 |
83-6120 |
DECAL-PARK-BRAKE,TILLER Price: $7.47 |
| 58 |
93-9363 |
DECAL-BRAKE, PARKING Price: $14.29 |
| 59 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 60 |
32105-2 |
SCREW-SHWH Price: $3.49 |
| 61 |
72-4080 |
DECAL-DANGER Price: $26.01 |
| 61 |
83-6010 |
DECAL-NO TOW, MOTOR ARM Price: $12.08 |
| 61 |
93-9371 |
DECAL-DANGER Price: $19.38 |
| 62 |
3220-6 |
NUT-JAM Price: $1.25 |
| 63 |
93-9388 |
DECAL-WARNING Price: $26.26 |
| 63 |
93-9429 |
DECAL-WARNING Price: $27.24 |
