| Ref | Part Number | Description |
|---|
| 1 |
136-3491 |
NO 1 LIFT ARM ASM This part replaces 114-0381-03. Price: $353.30 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
136-3494 |
NO 4 LIFT ARM ASM This part replaces 114-0384-03. Price: $501.83 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
136-3500 |
NO 5 LIFT ARM ASM This part replaces 114-0385-03. Price: $501.83 |
| 4 |
117-0208 |
SHAFT-PIVOT, LIFTARM Price: $96.42 |
| 5 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 6 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 7 |
117-0250-03 |
TIPPE-RH Price: $183.65 |
| 8 |
117-0252-03 |
TIPPER-LH Price: $183.65 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 10 |
87-3470 |
BUMPER Price: $18.89 |
| 11 |
327-7 |
SCREW-HH Price: $5.69 |
| 13 |
136-3515 |
CARRIER FRAME ASM This part replaces 108-7384-03. Price: $370.25 |
| 14 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 15 |
105-7560 |
SHAFT-CU PIVOT Price: $73.74 |
| 16 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 18 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 19 |
323-6 |
SCREW-HH Price: $0.66 |
| 20 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 21 |
325-5 |
SCREW-HH Price: $1.20 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
136-3568 |
PIN-FLAG (MACH) This part replaces 117-0132. Price: $14.65 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
322-3 |
SCREW-HH Price: $0.79 |
| 24 |
532108423 |
CABLE.BATTERY.6GA.16"RED Price: $6.99 |
| 25 |
117-0118 |
PIVOT ASM Price: $85.03 |
| 25 |
532165987 |
CABLE BATTERY Price: $22.99 |
| 26 |
323-11 |
SCREW-HH Price: $1.08 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532127725 |
CABLE GROUND Price: $4.18 |
| 28 |
99-7667 |
WASHER-FLAT Price: $4.80 |
| 29 |
105-9831-03 |
BRACKET-BUMPER, NO. 1 Price: $26.24 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 30 |
240-14 |
BUMPER-RUBBER Price: $13.84 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
104-7201 |
NUT-HF Price: $0.69 |
| 32 |
127-2613-03 |
GUARD-FOOT, LH Price: $52.42 |
| 33 |
127-2614-03 |
GUARD-FOOT, RH Price: $52.42 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532197434 |
RP HARNESS.IGN.ELECT.REG.CRD Price: $74.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 58 |
532169420 |
KIT.BUZZER.CRD This part replaces 532169419. Price: $64.99 |
| 59 |
583100701 |
SWITCH.FBI.CRD This part replaces 532180379. Price: $11.99 |
| 66 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 81 |
532109748 |
RELAY.ASSY.T Price: $19.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $19.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
