| Ref | Part Number | Description |
|---|
| 1 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 1 |
532429294 |
HEATER.BOX.ASSY-SNW(SKSN4100) Price: $89.99 |
| 2 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 3 |
108-6557 |
STEER VALVE AND COLUMN ASM This part replaces 92-7308. Price: $1,800.82 |
| 3 |
532429208 |
MUFFLER.ASSY.SNOW(SKSN4200) Price: $109.99 |
| 4 |
532429209 |
FUEL.TANK.ASSY.SNOW(SKSN4300) Price: $169.99 |
| 4 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 5 |
3220-6 |
NUT-JAM Price: $1.25 |
| 5 |
532424942 |
FUEL CAP OVERSIZED CLICK STYLE This part replaces 532429211. Price: $14.99 |
| 6 |
585020406 |
CARB.ASSY.W/O.SPACER.LCT.414CC This part replaces 532429295. Price: $119.99 |
| 6 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 7 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 8 |
233-17 |
KNOB Price: $10.58 |
| 8 |
595079601 |
PRIMER BULB.W/HOSE.LCT. This part replaces 532429218. Price: $8.99 |
| 9 |
63-7910 |
ROD-BRAKE, PARKING Price: $40.67 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
532429297 |
ELEC.START.ASSY.SNOW(SKSN4400) Price: $299.99 |
| 10A |
532437465 |
STARTER EUROPEAN 230V ELECTRIC Price: $449.99 |
| 11 |
532429221 |
KEY.SWITCH.ASSY.SNOW(SKSN4401) Price: $22.99 |
| 12 |
95-1821 |
SPRING-COMPRESSION Price: $6.71 |
| 13 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 13 |
532429223 |
ON/OFF.SWITCH.SNOW(SKSN4403) Price: $14.99 |
| 14 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 15 |
532429224 |
CHOKE.KNOW.SNOW(SKSN4500) Price: $7.99 |
| 15 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 16 |
108-1377 |
BRAKE CABLE ASM, RH This part replaces 63-7730. Price: $157.02 |
| 16 |
532429298 |
PLATE.GOVERN.LINK.S Price: $12.99 |
| 17 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 17 |
582621602 |
RECOIL STARTER KIT This part replaces 532429299. Price: $99.99 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 18 |
532429300 |
STARTER.CUP.SML.SNOW(SKSN4601) Price: $11.99 |
| 19 |
532443899 |
HANDLE.RECOIL.DELUXE.LCT This part replaces 532429301. Price: $14.99 |
| 19 |
63-6750 |
LINK-CABLE, BRAKE Price: $6.39 |
| 19A |
532443899 |
HANDLE.RECOIL.DELUXE.LCT Price: $14.99 |
| 20 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 20 |
532429302 |
BLOWER.HSG.ASSY.ELEC(SKSN4602 Price: $39.99 |
| 21 |
321-3 |
SCREW-HH Price: $0.28 |
| 21 |
532429231 |
SHIELD.CYLINDER.SNOW(SK4141010 Price: $3.99 |
| 22 |
532429232 |
SHIELD.U/FYWHL.CHARG(SKSN4604) Price: $4.99 |
| 22 |
63-6210-03 |
PIN-BRAKE This part replaces 63-6210. Price: $66.77 |
| 23 |
532429303 |
VALVE.COVER.LCT.414CC. Price: $27.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 25 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 25 |
532429234 |
FUEL.PETCOCK.SNOW(SKSN4900) Price: $14.99 |
| 26 |
532429304 |
FLYWHEEL.ASSY.ELEC.START Price: $149.99 |
| 26 |
63-6180 |
PEDAL-BRAKE, LH Price: $209.48 |
| 26A |
532429305 |
FLYWHEEL.ASSY.MAN.START Price: $69.99 |
| 26B |
532443900 |
FLYWHEEL.EL.ST.SKSN4408.1 Price: $169.99 |
| 27 |
256-42 |
BUSHING Price: $7.03 |
| 27 |
532429237 |
HIGHOIL.FILL.ASSY.KIT(SKSN4911 Price: $8.99 |
| 28 |
532429306 |
FLYWHEEL.FAN(SK4144000) Price: $29.99 |
| 28 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 29 |
532443944 |
IGNITION.COIL.(CDI).291-414CC Price: $54.99 |
| 29 |
63-6190 |
PEDAL-BRAKE, RH Price: $209.48 |
| 29A |
532443897 |
COIL.IGN.CDI.SKSN2403.1 Price: $32.99 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
532429308 |
CRANKCASE.CVR.ASSY(SK4143600) Price: $119.99 |
| 31 |
532435534 |
DIPSTK.OIL.BLK.LCTSK4143711.1 Price: $9.99 |
| 31 |
66-8140 |
HOSE-HYDRAULIC Price: $55.60 |
| 32 |
532429243 |
CHARGING.COIL.AC/DC(SK4141710) Price: $39.99 |
| 32 |
66-8630 |
TUBE-HYDRAULIC Price: $104.22 |
| 32A |
532443897 |
COIL.IGN.CDI.SKSN2403.1 Price: $32.99 |
| 33 |
532429290 |
ELECTRIC.START.BRKT(SKSN4405) Price: $11.99 |
| 33 |
66-8620 |
TUBE-HYDRAULIC Price: $125.76 |
| 34 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 34 |
532436966 |
SPARK.PLUG.BOOT.SNW,SKSN4691.1 Price: $14.99 |
| 35 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 36 |
237-30 |
O-RING Price: $2.50 |
| 36 |
532429310 |
GOVERNOR.ARM.ASSY(SKSN4502) Price: $7.99 |
| 37 |
532429311 |
GOVERNOR.SHAFT(SK4143100) Price: $6.99 |
| 37 |
66-8170 |
HOSE ASM Price: $100.76 |
| 38 |
237-22 |
O-RING Price: $2.43 |
| 38 |
532429312 |
GOVERNOR.GEAR.ASSY(SK4142900) Price: $17.99 |
| 39 |
21-9260 |
COVER-DUST Price: $8.19 |
| 39 |
532429313 |
CAMSHAFT(SK4141600) Price: $69.99 |
| 40 |
532429605 |
CYL.HEAD.ASSY.45 DEG.NON-GEN Price: $279.99 |
| 40 |
68-5370 |
DECAL Price: $6.21 |
| 41 |
32144-21 |
SCREW Price: $0.20 |
| 41 |
532424939 |
SPARK.PLUG(2083810) This part replaces 532429255. Price: $14.99 |
| 42 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 42 |
532429257 |
CDI.BOX.BRKT.SNOW(SKSN4402) Price: $4.99 |
| 43 |
84-7670 |
FOAM-COLUMN, SUPPORT Price: $7.53 |
| 44 |
532429315 |
PISTON.AND.ROD.ASSY(SK4141400) Price: $149.99 |
| 44 |
84-7660 |
CLAMP-COLUMN Price: $7.87 |
| 45 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 46 |
532429213 |
SHIELD.VAPOR(SKSN4606) Price: $44.99 |
| 47 |
532429316 |
OIL SEAL KIT NON-GENERATOR Price: $37.99 |
| 48 |
532429284 |
WIRE.HARNESS(SKSN4406) Price: $27.99 |
| 49 |
532429317 |
CRANKSHAFT.KEYED Price: $399.99 |
| 50 |
532435579 |
TOP.SHIELD.LCT. This part replaces 532429286. Price: $7.99 |
| 51 |
532429318 |
SKIRT FUEL TANK Price: $54.99 |
| 52 |
532429612 |
ROCKER ARM KIT Price: $19.99 |
| 53 |
532429606 |
PUSH ROD TAPPET KIT Price: $84.99 |
| 54 |
532429607 |
CYLINDER ASSY Price: $299.99 |
| 55 |
532429608 |
COUNTER WEIGHT KIT Price: $109.99 |
| 56 |
532429609 |
KIT.ENGINE GASKET.LCT.414CC Price: $37.99 |
| 57 |
532432146 |
FUEL HOSE KIT Price: $9.99 |
| 58 |
532432687 |
EXTENDED OIL DRAIN TUBE Price: $34.99 |
| 61 |
532432752 |
FUEL KNOB-SNOW Price: $7.99 |
| 62 |
532429242 |
NONREMVABLE.OIL.PLUG(SK4143715 Price: $8.99 |
| 63 |
532437464 |
SHIELD.MUFFLER. Price: $59.99 |
