| Ref | Part Number | Description |
|---|
| 1 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 1 |
532169831 |
CHASSIS STAMPING Price: $80.52 |
| 2 |
119-0000-03 |
CHANNEL-SUPPORT Price: $42.04 |
| 2 |
532165606 |
DRAWBAR Price: $59.99 |
| 3 |
112-7449 |
STRAP-SUPPORT This part replaces 112-7449-03. Price: $7.18 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
3212-8 |
SCREW-HH Price: $5.69 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
532155923 |
SADDLE FLAT Price: $11.99 |
| 7 |
117-4798-03 |
ARM-SUPPORT Price: $114.47 |
| 8 |
108-8646 |
SCREW-HH, LOCK Price: $2.85 |
| 8 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 9 |
112-7405 |
NUT-HEX, COUPLING Price: $33.55 |
| 10 |
17-7190 |
SPACER-FINGER Price: $6.51 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 12 |
110-0413 |
SEATBELT-RETRACTABLE Price: $286.99 |
| 13 |
3212-4 |
SCREW-HH Price: $2.73 |
| 13 |
532169118 |
PANEL DASH Price: $10.06 |
| 14 |
120-9017-0P |
LATCH-SEAT This part replaces 120-9017-03. Price: $19.73 |
| 15 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 16 |
120-9018 |
ROD-LATCH Price: $28.13 |
| 17 |
119-1414 |
PIN-COTTER, LOCKING Price: $0.54 |
| 17 |
532156051 |
HOOD - LT/YT This part replaces 532165378. Price: $549.99 |
| 18 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 19 |
83-1040 |
WASHER-FLAT Price: $2.31 |
| 20 |
323-9 |
SCREW-HH Price: $1.29 |
| 21 |
112-7264 |
SCREW-HH Price: $3.11 |
| 22 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 23 |
110-5954 |
MOUNT-CENTER, BONDED Price: $65.28 |
| 24 |
115-5519 |
WASHER-PLAIN Price: $7.28 |
| 24 |
596564401 |
Bolts This part replaces 532171031. Price: $3.99 |
| 25 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 26 |
93-5338 |
ROD-PROP Price: $124.99 |
| 27 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 28 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 28 |
532156880 |
GRILLE.LT.P/L HUSQVARNA.SERVIC This part replaces 532165379. Price: $256.99 |
| 29 |
325-18 |
SCREW-HH Price: $3.19 |
| 29 |
532149777 |
LENS LT/PL HUSQVARNA This part replaces 532165380. Price: $24.99 |
| 30 |
3296-45 |
NUT-HEX Price: $3.79 |
| 30 |
532165713 |
FENDER This part replaces 532167978. Price: $275.39 |
| 31 |
532165156 |
BRACKET SUPPORT FENDER Price: $5.99 |
| 31 |
702093 |
SCREW-HH Price: Call Us |
| 32 |
130-2701 |
SEAT AND SUSPENSION ASM Price: $3,063.06 |
| 33 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 33 |
532147203 |
FOOT REST LH Price: $9.15 |
| 34 |
532145243 |
FOOTREST LT/YT/GT RH This part replaces 532147202. Price: $9.15 |
| 34 |
5979 |
BUSHING-NYLINER Price: $3.19 |
| 35 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 36 |
137-5475-03 |
PLATE-SEAT Price: $332.94 |
| 37 |
2412-133 |
CLAMP-R Price: $3.19 |
| 38 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR This part replaces 532169834. Price: $9.99 |
| 39 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 40 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 41 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 42 |
322-3 |
SCREW-HH Price: $0.79 |
| 43 |
117-4059 |
NUT-HEX Price: $1.84 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
596135301 |
Washers This part replaces 532171224. Price: $2.99 |
| 53 |
532150067 |
BRACKET PNT PICK OFF LT/PL Price: $1.64 |
| 68 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532171018. Price: $3.99 |
| 102 |
532002751 |
CLIP T This part replaces 532124996. Price: $2.42 |
| 129 |
596582301 |
Washers This part replaces 532171225. Price: $2.99 |
| 134 |
532160219 |
ROD SUPPORT HOOD LT/PL HUS. Price: $7.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 162 |
532165672 |
BRACKET Price: $59.99 |
| 163 |
532165673 |
BRACKET Price: $43.99 |
| 164 |
532165605 |
SUPPORT Price: $59.99 |
| 165 |
583687501 |
COVER.BATTERY.CRD.BLACK.LT This part replaces 532167979. Price: $11.99 |
| 167 |
532165779 |
SUPPORT.ASM.BACKPLATE Price: $54.99 |
| 168 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK This part replaces 532171040. Price: $4.99 |
| 169 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532171041. Price: $3.99 |
| 174 |
532165939 |
BRACKET Price: $28.16 |
| 175 |
532166212 |
GUARD Price: $24.24 |
| 176 |
532192786 |
BAGGER.HINGE.PIN This part replaces 532128600. Price: $14.99 |
| 177 |
532132796 |
SPRING COVER LH Price: $5.99 |
| 179 |
532165942 |
ROD PIVOT Price: $7.99 |
| 184 |
532166139 |
BRACKET Price: $25.99 |
| 185 |
532165940 |
TUBE LEVER Price: $4.99 |
| 186 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532160793. Price: $5.99 |
| 198 |
532168937 |
NUT Price: $2.99 |
