| Ref | Part Number | Description |
|---|
| 1 |
39-3610 |
DISCONTINUED Price: Call Us |
| 1 |
530047721 |
Bulb-Purge Price: $3.99 |
| 2 |
530071717 |
Kit-Choke Lever Price: $7.99 |
| 2 |
66-6140 |
DECAL This part replaces 18-2180. Price: $25.48 |
| 3 |
29-0640 |
DISCONTINUED Price: Call Us |
| 3 |
530015843 |
Screw-tank Price: $1.99 |
| 4 |
29-0580 |
DISCONTINUED Price: Call Us |
| 4 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 5 |
29-0630 |
DISCONTINUED Price: Call Us |
| 5 |
530095646 |
Assy-Fuel pickup Price: $2.99 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 6 |
530069247 |
Kit-Fuel Line This part replaces 530071404. Price: $3.99 |
| 7 |
323-34 |
SCREW-HH Price: $0.54 |
| 7 |
530069216 |
Kit-Fuel/Purge line Price: $3.99 |
| 8 |
29-0590 |
SCREEN-FILLER Price: $150.99 |
| 8 |
530015775 |
Screw Price: $1.99 |
| 9 |
36-4950 |
CAP WA Price: $195.49 |
| 9 |
545000501 |
Cover-Air box Price: $3.99 |
| 10 |
11-6350 |
DISCONTINUED Price: Call Us |
| 10 |
545082301 |
Filter-Air Price: $2.99 |
| 11 |
530015849 |
Screw-Carb. Price: $1.99 |
| 11 |
92-7800 |
BATTERY COVER ASM This part replaces 24-9740. Price: $65.49 |
| 12 |
32140-43 |
DISCONTINUED Price: Call Us |
| 12 |
545000601 |
Box-Air Price: $4.99 |
| 13 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 14 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 15 |
237-103 |
DISCONTINUED Price: Call Us |
| 15 |
545075305 |
Assy-Fuel Tank This part replaces 545075304. Price: $11.99 |
| 16 |
29-2270 |
DISCONTINUED Price: Call Us |
| 16 |
530015771 |
Screw-Crankcase Price: $1.99 |
| 17 |
29-8720 |
DISCONTINUED Price: Call Us |
| 17 |
530015952 |
Screw-Shroud Price: $1.99 |
| 18 |
323-5 |
SCREW-HH Price: $0.41 |
| 18 |
545000701 |
Assy-Rear Shroud Price: $17.99 |
| 19 |
32103-2 |
NUT-WING Price: $0.68 |
| 20 |
29-0780 |
DISCONTINUED Price: Call Us |
| 20 |
530027593 |
Valve-Reed Price: $1.99 |
| 21 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 21 |
530029781 |
Stop-Reed Price: $1.99 |
| 22 |
29-0650 |
TOWER WA Price: $253.91 |
| 22 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 23 |
20-4690 |
TORO LOGO DECAL Price: $6.67 |
| 23 |
530015875 |
Screw-Retainer Price: $1.99 |
| 24 |
39-1020 |
DISCONTINUED Price: Call Us |
| 24 |
530055492 |
Isolator-Tank Price: $1.99 |
| 25 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
530054941 |
Ret.-Tank Price: $1.99 |
| 26 |
323-4 |
SCREW-HH Price: $1.02 |
| 26 |
530054834 |
Handle-Starter Price: $1.99 |
| 27 |
29-8970 |
WASHER *O Price: $6.65 |
| 27 |
545050409 |
Kit-Rope Price: $4.99 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
545081601 |
Bearing-Inner Price: $7.99 |
| 29 |
29-2130 |
DISCONTINUED Price: Call Us |
| 29 |
530015787 |
Retainer Price: $1.99 |
| 30 |
322-1 |
SCREW-HH Price: $0.22 |
| 30 |
530019158 |
Seal Price: $2.99 |
| 31 |
237-102 |
GROMMET Price: $62.07 |
| 31 |
530032102 |
Bearing-Outer Price: $8.99 |
| 32 |
39-0380 |
DISCONTINUED Price: Call Us |
| 32 |
530015789 |
Ret.-Crankshaft Price: $2.99 |
| 33 |
27-6630 |
DISCONTINUED Price: Call Us |
| 33 |
530028807 |
Assy-Crankshaft Price: $19.99 |
| 34 |
29-2380 |
DISCONTINUED Price: Call Us |
| 35 |
38-3790 |
DISCONTINUED Price: Call Us |
| 36 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
530055524 |
Assy-Flywheel Price: $22.99 |
| 37 |
32128-29 |
NUT-LOCK, FLANGE Price: $1.63 |
| 37 |
530016030 |
Washer Price: $1.99 |
| 38 |
29-0830 |
DISCONTINUED Price: Call Us |
| 38 |
530055620 |
Spacer Price: $4.99 |
| 39 |
321-3 |
SCREW-HH Price: $0.28 |
| 39 |
530015775 |
Screw-Baffle Price: $1.99 |
| 40 |
29-0610 |
DISCONTINUED Price: Call Us |
| 40 |
545115201 |
Plate-Baffle Price: $2.99 |
| 41 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 41 |
545050408 |
Kit-Pulley Price: $14.99 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 43 |
321-6 |
SCREW-HH Price: $0.25 |
| 43 |
530019182 |
Grommet Price: $1.99 |
| 44 |
322-3 |
SCREW-HH Price: $0.79 |
| 44 |
530016386 |
Screw-F/hsg. Price: $5.99 |
| 45 |
39-3630 |
DISCONTINUED Price: Call Us |
| 45 |
530059254 |
Assy-Fan Housing Price: $17.99 |
| 46 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 46 |
530094189 |
Washer-Clutch Price: $2.99 |
| 47 |
29-0620 |
DISCONTINUED Price: Call Us |
| 47 |
530055122 |
Assy-Clutch Price: $8.99 |
| 48 |
39-3640 |
DISCONTINUED Price: Call Us |
| 48 |
530150247 |
Assy-Drum/Adapter Price: $17.99 |
| 49 |
39-3670 |
DISCONTINUED Price: Call Us |
| 49 |
530010960 |
Assy-Conn. Rod Price: $14.99 |
| 50 |
29-8710 |
DISCONTINUED Price: Call Us |
| 50 |
530015162 |
Ret.-Piston pin Price: $1.99 |
| 51 |
29-9060 |
DISCONTINUED Price: Call Us |
| 51 |
530012594 |
Ring-Piston Price: $3.99 |
| 52 |
322-9 |
SCREW-HH Price: $3.09 |
| 54 |
530058846 |
Assy-Leadwire Price: $4.99 |
| 55 |
530016387 |
Bolt-Muffler 1/4"-20 Price: $1.99 |
| 57 |
545033201 |
Shield Price: $3.99 |
| 59 |
530012586 |
Cylinder Price: $17.99 |
| 61 |
530001624 |
Bolt-Cyl. 1/4"-20 Price: $1.99 |
| 62 |
545081826 |
Kit - Ignition Module This part replaces 530039234. Price: $32.99 |
| 63 |
530016357 |
Screw-Module Price: $1.99 |
