| Ref | Part Number | Description |
|---|
| 1 |
684-04168 |
Idler Pulley Assembly, 1.917 OD Price: $34.09 |
| 2 |
686-05033-4021 |
PULLEY SHIELD ASSEMBLY (CUB YELLOW 2) Not Available This part replaces 686-05033-0638. Price: |
| 3 |
986-05034 |
IDLER PULLEY ASSEMBLY Not Available Price: |
| 4 |
710-0136 |
Hex Cap Screw, 1/4-20 x 1.75 Price: $3.66 |
| 5 |
710-0151 |
Hex Head Screw, 3/8-24 x 2.00 Price: $6.55 |
| 6 |
710-0170 |
Hex Head Screw, 5/16-24 x .625 Price: $5.72 |
| 7 |
710-0502A |
Screw, 3/8-16 x 1.250 Price: $5.71 |
| 8 |
710-0599 |
Screw, 1/4-20 x 0.500 Price: $3.86 |
| 9 |
710-0606 |
Hex Head Screw, 1/4-20 x 1.50 Price: $4.67 |
| 10 |
710-0672 |
Hex Head Screw, 5/16-24 x 1.25 Price: $3.85 |
| 11 |
710-1309 |
Machine Screw, 5/16-18 x 0.750 Price: $3.86 |
| 12 |
710-1880 |
Hex Head Screw, 5/16-18 x .75, Patch Price: $4.02 |
| 13 |
710-3180 |
Hex Cap Screw, 5/16-18 x 1.75 Price: $4.93 |
| 14 |
712-04063 |
Flangelock Nut, 5/16-18, B&S Price: $3.56 |
| 15 |
712-04064 |
Flangelock Nut, 1/4-20 Price: $3.64 |
| 16 |
712-0700 |
Flange Nut, 9/16-18 Price: $10.12 |
| 17 |
714-0139 |
Square Key, 3/16 x 2.00 Price: $7.98 |
| 18 |
718-04407 |
Pulley Hub, 5/8 SPLINE Price: $11.11 |
| 19 |
786-04416B-0638 |
RH Mount Frame Price: $25.65 |
| 20 |
712-04064 |
Flangelock Nut, 1/4-20 Price: $3.64 |
| 21 |
932-04262 |
Extension Spring, .429 OD x 2.515 Price: $8.17 |
| 22 |
732-04276A |
Extension Spring Price: $8.55 |
| 23 |
936-0119 |
Washer, Lock, 5/16 Price: $4.29 |
| 24 |
736-0315 |
Washer, Flat, .760 x 1.50 x .120 Price: $5.94 |
| 25 |
736-0343 |
Washer, Flat, .330 x 1.25 x .120 Price: $3.90 |
| 26 |
736-04193 |
Washer, .396 x 1.140 x .095, B&S Price: $5.94 |
| 27 |
736-04511 |
Falt Washer, .255 x 1.00 x .060 Price: $2.94 |
| 28 |
736-0452 |
Bell Washer, .396 x 1.14 x .095 This part replaces 936-0452. Price: $4.05 |
| 29 |
736-3092 |
Washer, Flat, .265 x 1.0 x .030 Price: $3.68 |
| 30 |
786-05088 |
IDLER FORWARD BRACKET Not Available Price: |
| 31 |
738-04425 |
SHOULDER SCREW Price: $3.60 |
| 32 |
748-04087A |
Forward Idler Pivot Spacer Price: $5.66 |
| 33 |
750-04571 |
Spacer, Shoulder, .260 x .785 x .538 Price: $6.01 |
| 34 |
750-04907 |
Reverse Idler Pivot Spacer Price: $5.32 |
| 35 |
750-06392 |
IDLER SPACER PULLEY Not Available Price: |
| 38 |
756-05132 |
TRANSMISSION PULLEY Not Available Price: |
| 39 |
756-05151 |
PULLEY-ENG 3L & 4L (2) Not Available Price: |
| 40 |
756-0625 |
Cable Roller Price: $8.52 |
| 41 |
786-04343-0638 |
Cover Mounting Plate Price: $17.41 |
| 42 |
786-04346 |
Reverse Idler Bracket Price: $9.16 |
| 43 |
786-04357A-0638 |
Pulley Mounting Bracket Price: $9.67 |
| 44 |
786-04415D-0638 |
LH Mount Frame Price: $25.40 |
| 45 |
634P06425 |
WHEEL ASSEMBLY (13 x 5 x 6) (SBD GRAY) This part replaces 934-04232. Price: $148.42 |
| 46 |
710-05289 |
Hex Head Screw, 1/4-20 x 1.5 Price: $4.83 |
