| Ref | Part Number | Description |
|---|
| 1 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
321-4 |
SCREW-HH Price: $0.99 |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 3 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 4 |
38-2470 |
DISCONTINUED Price: Call Us |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 6 |
68-7330 |
DECAL - CAUTION This part replaces 27-4620. Price: $16.56 |
| 7 |
38-3170 |
DISCONTINUED Price: Call Us |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
321-2 |
SCREW-HH Price: $2.79 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 9 |
37-9770 |
DISCONTINUED Price: Call Us |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
323-5 |
SCREW-HH Price: $0.41 |
| 11 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
545145802 |
ASSY CRANKSHAFT This part replaces 530012579. Price: $17.99 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
3217-5 |
NUT-HEX Price: $0.25 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
33-0290 |
SEAT SWITCH Price: $86.62 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
3-6685 |
SPRING Price: $10.99 |
| 15 |
530016441 |
Screw Price: $1.99 |
| 16 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 18 |
32104-114 |
SCREW THD 1/4 20 5/8 Price: $5.17 |
| 18 |
530058709 |
Bulb - Purge Price: $4.99 |
| 19 |
545077501 |
Air Box Price: $7.99 |
| 19 |
68-7320 |
DISCONTINUED This part replaces 27-4390. Price: Call Us |
| 20 |
530016429 |
Screw Price: $1.99 |
| 20 |
67-1710 |
DECAL-WARNING This part replaces 28-3290. Price: $7.83 |
| 21 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 22 |
530057545 |
Cover-Air Box Price: $3.99 |
| 23 |
545081826 |
Kit - Ignition Module This part replaces 530039229. Price: $32.99 |
| 24 |
530059758 |
Spacer-Flywheel Price: $4.99 |
| 25 |
530016357 |
Screw Price: $1.99 |
| 26 |
530047834 |
Assy-Switch wire Price: $3.33 |
| 27 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 28 |
530054834 |
Handle-Starter Price: $1.99 |
| 29 |
530071798 |
Kit - Rope Price: $3.99 |
| 30 |
530055122 |
Assy-Clutch Price: $8.99 |
| 31 |
530094189 |
Washer-Clutch Price: $2.99 |
| 32 |
545016004 |
Assy.-Fan Hsg Price: $17.99 |
| 33 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 34 |
545050407 |
Kit-Starter Pulley Price: $11.99 |
| 35 |
545080601 |
Baffle Price: $6.99 |
| 36 |
530015880 |
Screw Price: $1.99 |
| 37 |
530016463 |
Washer-Clutch Flat Price: $1.99 |
| 38 |
530039243 |
Assy-Flywheel Price: $27.99 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
530055728 |
Outer Bearing Price: $6.99 |
| 42 |
530019264 |
Seal-C'shaft Price: $2.99 |
| 43 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 46 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 48 |
530016386 |
Screw Price: $5.99 |
| 49 |
530057539 |
Shroud-Rear Price: $7.99 |
| 50 |
530016445 |
Retainer-Tank Price: $1.99 |
| 52 |
530057973 |
Assy-Fuel Cap Price: $7.99 |
| 53 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 54 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 56 |
530071750 |
Kit-Engine Gasket Price: $8.99 |
| 58 |
545077301 |
Assy-Clutch Cover Price: $5.99 |
| 59 |
530016319 |
Screw-Align Price: $1.99 |
| 60 |
530015772 |
Screw Price: $1.99 |
| 61 |
530016381 |
Screw 12-24 Price: $2.99 |
| 62 |
530016382 |
Nut 12-24 Price: $2.99 |
