| Ref | Part Number | Description |
|---|
| 1 |
04434567 |
WLDMT, FOOTPEDAL Price: $33.95 |
| 2 |
04434467 |
WLDMT, REAR DECK LIFT Price: $47.95 |
| 3 |
04377367 |
WMT, LIFT/HOC LINK Price: $28.45 |
| 4 |
04377951 |
BRKT, HOC Price: $38.45 |
| 5 |
04391567 |
WMT, HOC LEVER Price: $199.95 |
| 6 |
04723751 |
GUARD, DECK HOC Price: $20.45 |
| 7 |
30193500 |
TRUNNION- DECK LIFT This part replaces 04377867. Price: $7.45 |
| 8 |
04377700 |
WIREFORM- DECK ADJUSTMENT This part replaces 04377767. Price: $16.45 |
| 9 |
05519100 |
BSHG-FLG .629X.879X.469X1.250 Price: $6.45 |
| 10 |
07525100 |
STOP Price: $1.95 |
| 11 |
08553700 |
BSHG-SLV .391X.688X.52 PM Price: $5.45 |
| 12 |
06700220 |
PIN, BOWTIE .091X1.875 ZCC This part replaces 06700201. Price: $2.45 |
| 13 |
07400130 |
SCR,TAP #10-24X.50 HWH TR ZCC This part replaces 07415800. Price: $1.95 |
| 14 |
05901711 |
BLT-HEX .38-16X1.00 G5 ZCC This part replaces 05948700. Price: $1.45 |
| 15 |
05901640 |
BLT,HEX .38-16X2.25 G5 ZCC This part replaces 05962900. Price: $3.95 |
| 16 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 17 |
06401118 |
WSHR, FLT .656X1.313X.095 ZCC This part replaces 06442800. Price: $2.45 |
| 18 |
06401023 |
WSHR-FLT .375X.875X.083 ZCC This part replaces 06435700. Price: $1.45 |
| 19 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 20 |
08335700 |
SG-COMP .125X.781X1.250 Price: $8.45 |
| 21 |
07533500 |
KNOB,BALL -BLACK 1.47" .375-16 Price: $8.95 |
| 22 |
06500917 |
NUT-STD .375-16 G2 ZCC This part replaces 06529400. Price: $0.95 |
| 23 |
06401106 |
WSHR, FLT .380X1.50X.125 ZCC This part replaces 06443400. Price: $3.45 |
| 24 |
06500822 |
NUT-LK-TOP-FLG .38-16 ZC120 This part replaces 06542000. Price: $0.95 |
| 25 |
07800334 |
DECAL, HEIGHT OF CUT Price: $9.45 |
| 26 |
06700225 |
PIN This part replaces 06700206. Price: $3.95 |
| 27 |
06443300 |
WSHR-FL-NYL .518X1.000X.080 Price: $0.45 |
| 28 |
04434667 |
WLDMT, DECK LIFT ARM Price: $33.95 |
| 29 |
05901740 |
BLT- HEX .25-20X2.00 G5 ZCC This part replaces 05967100. Price: $2.45 |
| 30 |
05501112 |
BSHG-SLV .265X.500X.500 Price: $3.45 |
