| Ref | Part Number | Description |
|---|
| 1 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 1 |
532140607 |
Transaxle Assembly 1-5/8 TT (AYP part number) Price: $599.99 |
| 2 |
3217-7 |
NUT-HEX Price: $0.28 |
| 2 |
532142431 |
Spring, Return, Brake (AYP part number) Price: $5.99 |
| 3 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 3 |
532144698 |
Pulley, Transaxle (AYP part number) Price: $22.99 |
| 4 |
32140-79 |
Screw Price: Call Us |
| 5 |
3-8602 |
DISCONTINUED Price: Call Us |
| 6 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 7 |
282-4 |
SHACKLE Price: $32.98 |
| 8 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 8 |
532141003 |
Rod Shift Fender LT (AYP part number) Price: $10.40 |
| 9 |
3-8718 |
DISCONTINUED Price: Call Us |
| 9 |
532145028 |
Clutch, Elect. EVX LT Mag 5217-2 (AYP part number) Price: $279.99 |
| 10 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 10 |
876020416 |
Pin Cotter 1/8 x 1 CAD (AYP part number) Price: $3.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 12 |
3-8601 |
DISCONTINUED Price: Call Us |
| 13 |
6-9960 |
DISCONTINUED Price: Call Us |
| 14 |
5-1640 |
DISCONTINUED Price: Call Us |
| 15 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 15 |
874780544 |
Bolt Fin Hex 5/16-18 Unc (AYP part number) Price: $3.99 |
| 16 |
3220-3 |
NUT-HJ Price: $0.28 |
| 16 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P (AYP part number) Price: $2.99 |
| 17 |
5-1637 |
DISCONTINUED Price: Call Us |
| 18 |
5-1660 |
DISCONTINUED Price: Call Us |
| 18 |
874780616 |
Bolt Fin Hex 3/8-16 Unc x 1 Gr. 5 (AYP part number) Price: $3.99 |
| 19 |
8-5129 |
DISCONTINUED This part replaces 6-0509. Price: Call Us |
| 19 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 20 |
38-7410 |
DISCONTINUED This part replaces 3-8597. Price: Call Us |
| 20 |
501606501 |
Speed Clip This part replaces 871170768. Price: $1.99 |
| 21 |
12-0300 |
DISCONTINUED Price: Call Us |
| 21 |
532121274 |
Knob, Duckhead 1/2-13 (AYP part number) Price: $5.99 |
| 22 |
352-276 |
DISCONTINUED Price: Call Us |
| 22 |
532145627 |
Rod, Brake Hydro (AYP part number) Price: $109.99 |
| 23 |
352-277 |
DISCONTINUED Price: Call Us |
| 23 |
532140275 |
Bracket, Asm Clutch Mtg EVX (AYP part number) Price: $14.99 |
| 24 |
352-272 |
DISCONTINUED Price: Call Us |
| 24 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 25 |
352-273 |
DISCONTINUED Price: Call Us |
| 25 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 26 |
352-268 |
DISCONTINUED Price: Call Us |
| 26 |
819131316 |
Washer (AYP part number) Price: $2.99 |
| 27 |
352-278 |
DISCONTINUED Price: Call Us |
| 27 |
876020412 |
Pin Cotter 1/8 x 3/4 CAD. (AYP part number) Price: $3.99 |
| 28 |
352-279 |
DISCONTINUED Price: Call Us |
| 28 |
532145204 |
Rod, Parking Brake (AYP part number) Price: $3.12 |
| 29 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 29 |
532071673 |
Cap, Parking Brake (AYP part number) Price: $3.99 |
| 30 |
352-270 |
DISCONTINUED Price: Call Us |
| 30 |
532130807 |
Bracket, Transaxle (AYP part number) Price: $3.99 |
| 31 |
12-0280 |
DISCONTINUED Price: Call Us |
| 31 |
532127275 |
Keeper Belt Lh (AYP part number) Price: $3.99 |
| 32 |
3-8596 |
SPRING-COMPRESSION Price: $29.97 |
| 32 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 33 |
5-3942 |
DISCONTINUED Price: Call Us |
| 33 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 34 |
5-1865 |
DISCONTINUED Price: Call Us |
| 34 |
532149001 |
Shaft, Foot Pedal (AYP part number) Price: $24.99 |
| 35 |
28-1520 |
DISCONTINUED This part replaces 6-1200. Price: Call Us |
| 35 |
532120183 |
Bearing, Nylon (AYP part number) Price: $2.99 |
| 36 |
3-8595 |
DISCONTINUED Price: Call Us |
| 36 |
819211616 |
Washer (AYP part number) Price: $3.99 |
| 37 |
5-3941 |
DISCONTINUED Price: Call Us |
| 37 |
532001572 |
Pin, Roll, 3/16 x 1 (AYP part number) This part replaces 532124963. Price: $3.99 |
| 38 |
3-8607 |
DISCONTINUED Price: Call Us |
| 38 |
532123674 |
Pulley, Idler, Flat (AYP part number) Price: $17.99 |
| 39 |
5-3953 |
DISCONTINUED Price: Call Us |
| 39 |
874760644 |
Bolt (AYP part number) Price: $3.99 |
| 40 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 40 |
532124965 |
Spacer, Split (AYP part number) Price: $3.99 |
| 41 |
5-1705 |
END SKID ASM Price: $139.95 |
| 41 |
532109070 |
Keeper, Belt Retainer (AYP part number) Price: $3.99 |
| 42 |
5-3965 |
DISCONTINUED Price: Call Us |
| 42 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 43 |
323-6 |
SCREW-HH Price: $0.66 |
| 44 |
5-3824 |
DISCONTINUED Price: Call Us |
| 44 |
532105706 |
Bearing, Nylon (AYP part number) Price: $3.99 |
| 45 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 45 |
532110812 |
Washer, Hardened (AYP part number) Price: $3.10 |
| 46 |
5-3835 |
DISCONTINUED Price: Call Us |
| 46 |
812000039 |
Ring, Klip (AYP part number) Price: $3.99 |
| 47 |
5-3950 |
DISCONTINUED Price: Call Us |
| 47 |
532139245 |
Pulley, Idler V Groove (AYP part number) This part replaces 532127783. Price: $22.99 |
| 48 |
11-4929 |
DISCONTINUED This part replaces 5-3944. Price: Call Us |
| 48 |
532123789 |
Bellcrank Assembly (AYP part number) Price: $13.07 |
| 49 |
5-2186 |
REEL BEARING Price: $45.95 |
| 49 |
532123205 |
Retainer, Belt (AYP part number) Price: $3.99 |
| 50 |
5-3838 |
DISCONTINUED Price: Call Us |
| 50 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 874760624. Price: $3.99 |
| 51 |
253-121 |
DISCONTINUED Price: Call Us |
| 51 |
873680600 |
Nut Price: $1.99 |
| 52 |
5-2182 |
DISCONTINUED Price: Call Us |
| 52 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 53 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 54 |
3296-45 |
NUT-HEX Price: $3.79 |
| 55 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 55 |
532105709 |
Spring, Return, Clutch (AYP part number) Price: $7.99 |
| 56 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 56 |
874760620 |
Bolt Fin Hex 3/8-16 UNC x 1-1/4 (AYP part number) Price: $3.99 |
| 57 |
5-3915 |
DISCONTINUED Price: Call Us |
| 57 |
532141416 |
V-Belt, Ground Drive (AYP part number) Price: $39.99 |
| 58 |
5-3918 |
DISCONTINUED Price: Call Us |
| 59 |
5-3837 |
DISCONTINUED Price: Call Us |
| 59 |
532169691 |
KEEPER, BELT CENTER This part replaces 532140312. Price: $14.99 |
| 60 |
5-3966 |
DISCONTINUED Price: Call Us |
| 60 |
532105730 |
Keeper, Belt Engine (AYP part number) Price: $2.99 |
| 61 |
5-1704 |
DISCONTINUED Price: Call Us |
| 61 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 62 |
2-1590 |
DISCONTINUED Price: Call Us |
| 62 |
532008883 |
PEDAL COVER This part replaces 532124872. Price: $3.99 |
| 63 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 63 |
532145868 |
Pulley, Clutch Electric EVX (AYP part number) Price: $44.99 |
| 64 |
322-2 |
SCREW-HH Price: $0.69 |
| 65 |
3279-2 |
DISCONTINUED Price: Call Us |
| 65 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 68 |
532121218 |
Keeper Belt Engine (AYP part number) Price: $2.86 |
| 69 |
532142432 |
Screw (AYP part number) Price: $3.99 |
| 71 |
532141417 |
Strap Torque Lh Hydro (AYP part number) Price: $3.99 |
| 73 |
532141418 |
Strap Torque Rh Hydro (AYP part number) Price: $3.99 |
| 74 |
532121199 |
Spacer, Split (AYP part number) Price: $3.12 |
| 75 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Gauge (AYP part number) Price: $1.99 |
| 76 |
812000001 |
E-Ring (AYP part number) Price: $2.99 |
| 77 |
532123583 |
Key, Square (AYP part number) Price: $2.99 |
| 78 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Gauge (AYP part number) Price: $1.99 |
| 81 |
532141420 |
Shaft Asm. Cross Hydro (AYP part number) Price: $37.99 |
| 82 |
532123782 |
Spring Torsion T/A (AYP part number) Price: $2.99 |
| 83 |
734117771 |
BUSHING This part replaces 819171216. Price: $2.99 |
| 84 |
532141423 |
Rod, Tie Hydro (AYP part number) Price: $49.99 |
| 86 |
532071208 |
Bushing Rod Steering 629/632 ID (AYP part number) Price: $3.99 |
| 87 |
819212016 |
Washer 21/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $3.99 |
| 88 |
812000008 |
Ring Klip #5304-62 (AYP part number) Price: $3.99 |
| 89 |
532153764 |
CONSOLE This part replaces 532139988. Price: $12.99 |
| 91 |
874780536 |
Bolt Fin Hex 5/16-18 x 2-1/4 (AYP part number) Price: $2.99 |
| 92 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 93 |
532142564 |
Line Fuel Hydro 4" (AYP part number) Price: $3.99 |
| 94 |
532140462 |
Fan, Hydro 7" (AYP part number) Price: $7.99 |
| 95 |
532167696 |
CONTROL.ASM.BYPASS.HYDRO.99 This part replaces 532144643. Price: $8.99 |
| 96 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 97 |
532144201 |
Keeper Belt Rh Hydro (AYP part number) Price: $8.99 |
| 98 |
873510600 |
Nut Keps Hex 3/8-16 Unc (AYP part number) Price: $3.99 |
| 100 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
| 103 |
873940800 |
Nut Nylon Insert 1/2-20 Unf. (AYP part number) Price: $3.99 |
| 104 |
532141421 |
Arm, Control Hydro (AYP part number) Price: $2.99 |
| 105 |
871070516 |
Screw Cap Hex 5/16 x 18 x 1 (AYP part number) Price: $2.99 |
| 106 |
874520520 |
BOLT.5/16-18X1-1/4 FULL THD This part replaces 874780520. Price: $2.99 |
| 108 |
817541026 |
Screw Hex Wh Hd #10-24 x (AYP part number) Price: $2.99 |
| 109 |
532145098 |
Adaptor Fan Hydro LT Hyd Alum (AYP part number) Price: $27.11 |
