Fuel Tank
Parts (29)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 121-4703 | GROOMER SHAFT ASM Price: $443.41 |
| 1 | 490892635 | Shround-Engine "A" Price: $39.99 |
| 2 | 140-5580 | BLADE-GR GROOMER, TWIN TIP (0.032") This part replaces 110-2343. Price: $3.65 |
| 2 | 545145463 | Screw m5x10 Price: $1.99 |
| 3 | 140-5616 | SPACER-SS This part replaces 70-1350. Price: $2.60 |
| 3 | 490892612 | Shround-Engine Price: $11.99 |
| 4 | 120-9653 | NUT-LOCK, NI Price: $3.53 |
| 4 | 920552205 | O-Ring 31.2 i.d. Price: $1.99 |
| 5 | 110382091 | Assy-Air filter case Price: $24.99 |
| 5 | 140-5606 | SPACER-SS This part replaces 107-4430. Price: $2.49 |
| 6 | 920092359 | Screw m3x10 Price: $1.99 |
| 7 | 131682493 | Lever Price: $3.99 |
| 8 | 161262241 | Valve Price: $3.99 |
| 9 | 110292022 | Element-Air Filter Price: $17.99 |
| 10 | 110652119 | Cap-Air Filter Price: $14.99 |
| 11 | 921532107 | Bolt m5x18 Price: $2.99 |
| 12 | 545145466 | Screw m5x55 Price: $2.99 |
| 13 | 510482083 | Cap-Assy tank Price: $11.99 |
| 14 | 140692088 | Breather Price: $8.99 |
| 15 | 999966089 | Assy-Cap/Breather Price: $27.99 |
| 16 | 545145480 | Band Price: $27.99 |
| 17 | 545145479 | Fuel Tank Price: $109.99 |
| 18 | 921702110 | Clamp Price: $1.99 |
| 19 | 921922086 | Tube 2.3x5x93 Price: $1.99 |
| 20 | 490432073 | Pump-Priming carb Price: $14.99 |
| 21 | 921912136 | Tube 3x5x300 Price: $4.99 |
| 22 | 921712073 | Clamp Price: $1.99 |
| 23 | 921922150 | Tube 3x6x160 "A" Price: $9.99 |
| 24 | 920712142 | Grommet-tank Price: $2.99 |
