| Ref | Part Number | Description |
|---|
| 1 |
321-3 |
SCREW-HH Price: $0.28 |
| 2 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 3 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 4 |
49-9730 |
DISCONTINUED Price: Call Us |
| 5 |
49-9620 |
DASH WA *R Price: $393.16 |
| 6 |
39-9600 |
MTG CLAMP F/W GUAGE Price: $19.63 |
| 7 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 8 |
33-0990 |
DISCONTINUED Price: Call Us |
| 9 |
3256-21 |
WASHER-FLAT Price: $0.25 |
| 10 |
51-0730 |
DISCONTINUED Price: Call Us |
| 11 |
12-8140 |
KEY SWITCH Price: $39.86 |
| 12 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 13 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 14 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 15 |
19-2090 |
CHOKE CONTROL Price: $44.46 |
| 16 |
3219-3 |
NUT-HEX Price: $0.34 |
| 17 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 18 |
218-515 |
BRACKET Price: $12.11 |
| 19 |
3251-2 |
SCREW-PPH Price: $0.27 |
| 20 |
233-25 |
KNOB-CONTROL Price: $4.48 |
| 21 |
9547 |
WASHER-THRUST This part replaces 25-6260. Price: $5.69 |
| 22 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 23 |
25-8140 |
STEERING SHAFT Price: $36.04 |
| 24 |
51-0680 |
THROTTLE CONTROL Price: $42.15 |
| 25 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 26 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 27 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 28 |
3217-26 |
NUT-HEX Price: $0.25 |
| 29 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 30 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 31 |
27-5170 |
SEAT Price: $246.87 |
| 32 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 33 |
72-9520 |
SEAT PLATE *B This part replaces 49-9910. Price: $48.22 |
| 34 |
51-0780 |
SLIDER-SEAT Price: $116.02 |
| 35 |
322-2 |
SCREW-HH Price: $0.69 |
| 36 |
25-8160-03 |
DISCONTINUED This part replaces 25-8160. Price: Call Us |
| 37 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 38 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 39 |
51-0790 |
ADJUSTER-SEAT, LH Price: $127.92 |
| 40 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 41 |
6-1600 |
SOLENOID Price: $55.95 |
| 42 |
32104-95 |
SCREW-HWH This part replaces 32104-42. Price: $0.41 |
| 43 |
2412-73 |
CLAMP-R Price: $2.56 |
| 44 |
18-6340 |
STEERING SHAFT-LOWER Price: $20.30 |
| 45 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 46 |
18-6370 |
CHAIN Price: $39.34 |
| 47 |
32103-12 |
NUT-WING Price: $1.15 |
| 48 |
7-3328 |
DISCONTINUED Price: Call Us |
| 49 |
47-1680 |
BATTERY HOLD DOWN Price: $10.11 |
| 50 |
218-331 |
BATTERY BOOT Price: $9.89 |
| 51 |
3230-15 |
SCREW-CARR Price: $1.49 |
| 52 |
49-7030 |
SEE SB MISC 14 Price: Call Us |
| 53 |
52-1460 |
GRND.CABLE Price: $17.16 |
| 54 |
84-7870 |
DISCONTINUED This part replaces 18-7840. Price: Call Us |
| 55 |
18-6560 |
WIRE-BLACK Price: $27.76 |
| 56 |
51-0710 |
WIRE HARNESS Price: $72.27 |
| 57 |
18-7830 |
WIRE SOLENOID-B SWTH Price: $12.78 |
| 58 |
18-6580 |
DISCONTINUED Price: Call Us |
| 60 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 61 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 62 |
2710-31 |
LINK-CONNECTING, NO. 35 Price: $1.68 |
| 63 |
17-2490 |
SPROCKET Price: $45.34 |
| 64 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 65 |
51-0720 |
DISCONTINUED Price: Call Us |
| 66 |
3219-14 |
NUT-HEX Price: $0.25 |
| 67 |
32128-20 |
NUT-HF This part replaces 32128-2. Price: $0.99 |
| 68 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 69 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 70 |
46-6890 |
DISCONTINUED This part replaces 11-4659. Price: Call Us |
| 71 |
322-1 |
SCREW-HH Price: $0.22 |
| 72 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
