| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER Price: $188.53 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
530057541 |
Hsg.-Throttle right Price: $7.99 |
| 2 |
530059759 |
Assy-Throttle Cable Price: $9.99 |
| 3 |
282-4 |
SHACKLE Price: $32.98 |
| 3 |
530016406 |
Screw. Price: $1.99 |
| 4 |
32151-48 |
E-RING Price: $1.41 |
| 4 |
530015814 |
Screw Price: $1.49 |
| 5 |
530054183 |
Assy-Wire Price: $4.99 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
530059760 |
Hsg. - Throttle left Price: $6.99 |
| 7 |
545049301 |
KIT SWITCH This part replaces 545030601. Price: $5.99 |
| 7 |
98-4548-03 |
BRACKET-SPRING, RH Price: $42.16 |
| 8 |
530049107 |
Trigger This part replaces 545077601. Price: $1.99 |
| 8 |
98-4536-03 |
BRACKET-SPRING, LH Price: $42.16 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
530059185 |
Clamp-Handle Price: $2.99 |
| 11 |
100-3831-01 |
BRACKET-ROLLER, LH Price: $69.47 |
| 11 |
530401992 |
Wingnut This part replaces 530016152. Price: $2.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
530056570 |
Flex-Lower Price: $14.99 |
| 13 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 13 |
530057987 |
Clamp-Lower Price: $3.99 |
| 14 |
530015940 |
Screw Price: $1.99 |
| 14 |
75-5400 |
PIN-ROLLER Price: $26.06 |
| 15 |
530015820 |
Bolt Price: $1.99 |
| 15 |
75-5390 |
ROLLER Price: $56.69 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 16 |
530057986 |
Clamp-Upper Price: $2.99 |
| 17 |
75-5360 |
PIN-CYLINDER Price: $72.33 |
| 18 |
108-4432 |
CYLINDER-HYD, LIFT This part replaces 93-9311. Price: $730.09 |
| 18 |
530016344 |
Screw Price: $1.99 |
| 19 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 19 |
545008090 |
Assy-Driveshaft Price: $31.99 |
| 20 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 20 |
530094417 |
Shoulder Strap This part replaces 530094408. Price: Call Us |
| 21 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 23 |
93-0069-03 |
PIN-REAR Price: $424.34 |
| 25 |
322-6 |
SCREW-HH Price: $0.45 |
| 26 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
