| Ref | Part Number | Description |
|---|
| 1 |
130-5830 |
HOUSING-HEAT/AC Price: $812.85 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 2 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
114-4899 |
PLUG-PLASTIC Price: $0.39 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
104-7201 |
NUT-HF Price: $0.69 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
130-5834 |
BRACKET-SUPPORT Price: Call Us |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
130-5821 |
BRACKET-AIRBOX, SIDE Price: $10.72 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
125-7504 |
PLATE-BACKER, CENTER Price: $5.77 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
130-0554 |
BRACKET-AIRBOX, CENTER Price: $18.34 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
130-5601 |
DRAIN-LOWER Price: $35.83 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
108-0342 |
FITTING-STRAIGHT Price: $5.86 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
121-6840 |
WASHER-RUBBER Price: $1.29 |
| 12 |
107-3041 |
WASHER-FLAT Price: $0.54 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
