| Ref | Part Number | Description |
|---|
| 1 |
49-5430 |
ROD-CONTROL Price: $75.94 |
| 1 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. This part replaces 532429196. Price: $11.99 |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
574841103 |
DECAL, CONSOLE HUS Price: $17.99 |
| 3 |
282-2 |
YOKE Price: $30.04 |
| 3 |
586342501 |
DECAL.ZTR.STRTNGINST.REMOTECHK Price: $3.99 |
| 4 |
283-61 |
PIN-YOKE Price: $1.56 |
| 5 |
44-0870 |
CAM SHAFT ASM Price: $213.32 |
| 5 |
585658901 |
DECAL.MZ52 Price: $9.99 |
| 6 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 6 |
539105744 |
DECAL, BELT DRIVE Price: $5.99 |
| 7 |
27-2320 |
BEARING Price: $15.22 |
| 7 |
529527001 |
Decals This part replaces 539105745. Price: $2.99 |
| 8 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 8 |
589283001 |
DECAL.ZTR.MOTCONTRL.SYMBOL.HUS Price: $3.99 |
| 9 |
49-6220 |
BRACKET-ARM, CONTROL Price: $28.06 |
| 9 |
539112620 |
DECAL, BELT ROUTING Price: $4.99 |
| 10 |
256-251 |
BUSHING Price: $2.46 |
| 10 |
539132039 |
DECAL, HEIGHT ADJUST Price: $4.99 |
| 11 |
233-48 |
KNOB Price: $10.92 |
| 11 |
539132187 |
DECAL, SERVICE Price: $3.99 |
| 12 |
589357902 |
NEEDS DESCRIPTION This part replaces 589357901. Price: $1.99 |
| 12 |
93-9934 |
TRACTION HANDLE ASM Price: $86.68 |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 13 |
581724401 |
DECAL.DECK.6MIL./DEF.SHLD.WARN Price: $3.99 |
| 14 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 14 |
590485501 |
DECAL ZTR WARNING DECAL DECAL. This part replaces 583934001. Price: $9.99 |
| 15 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 15 |
574455001 |
DECAL, CROWN H, 110MM Price: $8.99 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 16 |
585142601 |
DECAL.STR.S.T.SYSMBOLONLY.2014 Price: $3.99 |
| 17 |
501082601 |
DECAL CERTIFICATION DECAL EMCC Price: $12.99 |
| 17 |
57-6220 |
LINK-CONNECTING Price: $6.01 |
| 18 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 18 |
581724102 |
DECAL.80.DBA.AUSTRALIA Price: $4.99 |
| 19 |
3211-2 |
SCREW-HH Price: $2.17 |
| 19 |
585302301 |
Decals This part replaces 574569002. Price: $3.99 |
| 20 |
574569005 |
DECAL ROPS Price: $3.99 |
| 20 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 21 |
49-6260 |
PIVOT ASM Price: $79.73 |
| 21 |
584904602 |
DECAL.DECK.DEFLECTOR.WARNING This part replaces 584904601. Price: $1.99 |
| 22 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 22 |
539977778 |
ANTI-SKID PAD Price: $3.99 |
| 23 |
539121322 |
FOOT PAD Price: $3.99 |
| 23 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 24 |
83-0540-01 |
TRACTION PEDAL ASM This part replaces 83-0540. Price: $70.97 |
| 25 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 26 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 28 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 29 |
83-0630 |
ARM-PIVOT, TRACTION Price: $25.47 |
| 30 |
2411-42 |
JOINT-BALL, LH Price: $19.07 |
| 31 |
3220-20 |
NUT-JAM Price: $0.92 |
| 32 |
83-0580 |
ROD-CONTROL, TRACTION Price: $53.72 |
| 33 |
2411-43 |
JOINT-BALL Price: $21.40 |
| 34 |
77-0480 |
SCREW - STOP Price: $2.18 |
| 35 |
49-6250 |
BRACKET-PIVOT Price: $22.09 |
| 36 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 37 |
49-6290 |
PIVOT SHAFT ASM Price: $25.43 |
| 38 |
12-3270 |
SCREW Price: $3.09 |
| 39 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 40 |
47-5320-01 |
LEVER This part replaces 47-5320. Price: $84.02 |
| 41 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 42 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 43 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 44 |
93-9936 |
BRACKET-RETURN, TRACTION Price: $6.79 |
| 45 |
93-9937 |
TRACTION CABLE ASM Price: $28.43 |
| 46 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 47 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 48 |
3217-6 |
NUT-HEX Price: $1.19 |
