| Ref | Part Number | Description |
|---|
| 1 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 2 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 3 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 4 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 7 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
66-8610 |
DISCONTINUED Price: Call Us |
| 11 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 12 |
76-1910 |
DISCONTINUED Price: Call Us |
| 13 |
82-9060 |
DISCONTINUED Price: Call Us |
| 14 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 15 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 16 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 17 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 18 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 19 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 20 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 21 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 22 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 23 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 24 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 26 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 27 |
93-3164 |
CAP Price: $11.64 |
| 28 |
93-3163 |
SPRING Price: $26.01 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 501220001 |
501220001 |
SCREEN Price: $0.99 |
| 501220101 |
501220101 |
LOCKING RING Price: $0.69 |
| 501220201 |
501220201 |
PLUG (TIL 179-60X) Price: $2.25 |
| 501220301 |
501220301 |
Plug Price: $0.85 |
| 501220401 |
501220401 |
BALL Price: $11.99 |
| 501220501 |
501220501 |
SPRING Price: $3.99 |
| 501220801 |
501220801 |
GASKET, METERING SIDE Price: $3.99 |
| 501220901 |
501220901 |
METERING DIAPHRAGM Price: $14.99 |
| 501221101 |
503486301 |
COVER SCREW This part replaces 501221101. Price: $3.99 |
| 501221201 |
501221201 |
FUEL PUMP DIAPHRAGM Price: $7.99 |
| 501221301 |
501221301 |
GASKET, PUMP SIDE Price: $3.99 |
| 501221401 |
501221401 |
CAP Price: $27.99 |
| 501221501 |
501221501 |
SCREW Price: $3.99 |
| 501221701 |
501221701 |
SPRING Price: $3.99 |
| 501222001 |
501222001 |
LEVER Price: $4.99 |
| 501222101 |
501222101 |
SHAFT Price: $6.99 |
| 501222401 |
578004601 |
FILTER This part replaces 501222401. Price: $0.99 |
| 501222501 |
501222501 |
SPRING Price: $3.99 |
| 501223001 |
503652701 |
SCREW This part replaces 501223001. Price: $4.99 |
| 501238801 |
503534001 |
NIPPLE This part replaces 501238801. Price: $14.99 |
| 501268501 |
501268501 |
IDLE ADJ. SCREW Price: $17.99 |
| 501268901 |
501268901 |
NEEDLE H Price: $6.99 |
| 501269001 |
501269001 |
SPRING Price: $4.99 |
| 501289201 |
501289201 |
SLEEVE Price: $4.99 |
| 501427101 |
501427101 |
Bushing Price: $1.00 |
| 501466701 |
503117001 |
VALVE/INLET. This part replaces 501466701. Price: $19.99 |
| 501483701 |
501483701 |
SHAFT Price: $25.58 |
| 501483802 |
501483802 |
GOVERNOR Price: $18.27 |
| 501485001 |
501485001 |
GASKET Price: $0.67 |
| 501485201 |
501485201 |
SCREW Price: $4.99 |
| 501494802 |
501494802 |
DIAPHRAGM SET Price: $17.99 |
| 501552101 |
501815801 |
SPRING This part replaces 501552101. Price: $2.07 |
| 501611501 |
501611501 |
Price: Call Us |
| 501691101 |
501691101 |
THROTTLE FLAP Price: $6.99 |
| 501821601 |
501821601 |
THROTTLE SHAFT Price: $6.28 |
| 501821801 |
501821801 |
RETAINING RING Price: $7.99 |
| 501821901 |
501821901 |
CAP Price: $5.98 |
| 502012201 |
502012201 |
CHOKE FLAP Price: $2.62 |
