| Ref | Part Number | Description |
|---|
| 1 |
137-6113 |
LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 114-5415. Price: $383.80 |
| 1 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
532141342 |
Keeper,Mower Drive, R. H. (AYP part number) Price: $4.99 |
| 4 |
532138029 |
Pulley, Engine (AYP part number) Price: $49.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
871170744 |
Bolt Hex 7/16-20 Gr. 5 (AYP part number) Price: $2.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
532124525 |
Traction, V-Belt Drive (AYP part number) Price: $34.99 |
| 8 |
532164173 |
KEEPER.BELT.ENGINE This part replaces 532123405. Price: $4.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
872140612 |
Bolt, Carr.?? 3/8-16 UNC x 1-1/2 (AYP part number) Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532123396 |
Keeper, Belt Ground Drive Idler (AYP part number) Price: $4.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532140911 |
Arm, Ground Drive Clutch (AYP part number) Price: $4.35 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532123674 |
Idler, Flat (AYP part number) Price: $17.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 16 |
532126471 |
Clip, Insulated (AYP part number) Price: $2.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 18 |
532131459 |
Spring Extension (AYP part number) Price: $4.99 |
| 19 |
873510500 |
Nut, Keps 5/16-18 UNC (AYP part number) Price: $5.99 |
| 20 |
532139919 |
Keeper, T/A Ground Drive Belt (AYP part number) Price: $2.99 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. (AYP part number) Price: $5.99 |
| 22 |
532123404 |
Keeper, Frame Ground Drive Belt (AYP part number) Price: $3.22 |
| 23 |
532140916 |
Keeper, Mower Drive, L. H. (AYP part number) Price: $5.99 |
