| Ref | Part Number | Description |
|---|
| 1 |
601001864 |
GEARCASE HALF - RIGHT Price: $25.28 |
| 1 |
DDT468050604BE |
HOOD-UPPER Not Available Price: |
| 2 |
601001865 |
GEARCASE HALF - LEFT Price: $23.15 |
| 2 |
DD-T4620-50672 |
CUSHION-RUBBER Not Available Price: |
| 3 |
601000615 |
DRUM Price: $40.87 |
| 3 |
DD-01754-50820 |
HEX FLANGE BOLT Not Available Price: |
| 4 |
601001298 |
SEALANT/GASKET ELIMINATOR NLA Price: $73.45 |
| 4 |
DD-T4620-80691 |
WASHER Not Available Price: |
| 5 |
601000297 |
SEAL - OIL Price: $10.99 |
| 5 |
DD-01754-50820 |
HEX FLANGE BOLT Not Available Price: |
| 6 |
601000437 |
BEARING Price: $6.99 |
| 6 |
DDT462550701BE |
COVER-HOOD ACCESS Not Available Price: |
| 7 |
601000601 |
WASHER, THRUST - TORR TRA Price: $1.99 |
| 7 |
DDT426550731BE |
Cover Ass'y Price: Call Us |
| 8 |
601000600 |
NEEDLE BEARING Price: $8.99 |
| 9 |
601000424 |
WASHER, THRUST - INA TWD Price: $6.27 |
| 9 |
DD-01023-50612 |
HEX BOLT Not Available Price: |
| 10 |
601000296 |
SHAFT, WORM Price: $59.99 |
| 10 |
DD-T4260-19141 |
CUSHION-HOOD Not Available Price: |
| 11 |
601000603 |
SHAFT/GEAR - LONG Price: $170.99 |
| 11 |
DD-T4620-50634 |
HANDLE-HOOD LOCK Not Available Price: |
| 12 |
601000671 |
WASHER, FLAT .506X .75X. Price: $3.99 |
| 12 |
DD-32240-23951 |
WASHER Not Available Price: |
| 13 |
601000567 |
BRNG, FL .502IDX .752OD Price: $5.99 |
| 13 |
DD-T4620-50612 |
PLATE-FRONT GRILLE Not Available Price: |
| 14 |
601001866 |
SEAL, OIL, .75 X 1.19 X .25 Price: $6.17 |
| 14 |
DD-76KP-0603 |
WASHER Not Available Price: |
| 15 |
601000298 |
BEARING - TINE SHAFT Price: $6.20 |
| 15 |
DD-04015-50080 |
FLAT WASHER Not Available Price: |
| 16 |
601000324 |
SCREW Price: $1.54 |
| 16 |
DD-02156-50080 |
HEX NUT Not Available Price: |
| 17 |
601000644 |
WASHER, FLAT .515X .94X. Price: $4.81 |
| 17 |
DD-T4620-50652 |
SPRING-GRILLE PLAT Not Available Price: |
| 18 |
601000421 |
SCREW Price: $1.99 |
| 18 |
DD-T4260-18031 |
BOLT-GUIDE Not Available Price: |
| 19 |
601000325 |
SCREW Price: $4.81 |
| 19 |
DD-04512-50060 |
LOCK WASHER Not Available Price: |
| 20 |
601002010 |
GASKET, GEAR CASE Price: $14.99 |
| 20 |
DD-02056-50060 |
HEX NUT Not Available Price: |
| 21 |
601000598 |
WASHER, FLAT .76 X1.25X. Price: $3.99 |
| 21 |
DD-T4620-50662 |
HOOK ASSEMBLY-STRAP & Not Available This part replaces DD-T4620-50663. Price: |
| 22 |
DD-T4810-50661 |
CUSHION-HOOD Not Available Price: |
| 23 |
601000434 |
GREASE FITTING NLA Price: $7.17 |
| 23 |
DD-55314-37171 |
WASHER Not Available Price: |
| 24 |
DD-T4625-50711 |
PLATE-ACCESS COVER Not Available Price: |
| 25 |
DD-T4625-50722 |
ACCESS COVER PLATE Not Available This part replaces DD-T4625-50721. Price: |
