| Ref | Part Number | Description |
|---|
| 1 |
93-3670 |
O-RING Price: $28.85 |
| 2 |
601505129 |
NUT 5/16-18 Price: $5.99 |
| 2 |
72-5740 |
OIL SEAL Price: $31.19 |
| 3 |
251-348 |
BEARING-BALL Price: $54.23 |
| 3 |
532198552 |
WASHER, LOCK 5/16 This part replaces 601400079. Price: $6.99 |
| 4 |
601505130 |
TANK, FUEL Price: $34.99 |
| 4 |
72-5720 |
RETAINING RING Price: $6.96 |
| 5 |
601505131 |
RING, FOAM FUEL TANK Price: $11.99 |
| 5 |
72-5580 |
BEVEL GEAR Price: $289.19 |
| 6 |
251-8 |
BEARING-BALL Price: $30.06 |
| 6 |
601505132 |
FUEL CAP Price: $11.99 |
| 7 |
601400080 |
WASHER, FLAT .281X.63 Price: $4.99 |
| 7 |
93-3671 |
PIN Price: $15.63 |
| 8 |
601505133 |
SCREW 1/4-20X.75 Price: $2.99 |
| 8 |
93-3672 |
DISCONTINUED Price: Call Us |
| 9 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 9 |
601505134 |
BRACKET, FUEL TANK Price: $12.99 |
| 10 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 10 |
601001419 |
NUT Price: $3.13 |
| 11 |
601001348 |
SCREW, 1/4-20 X 2.00 Price: $3.28 |
| 12 |
251-347 |
BEARING-BALL Price: $9.69 |
| 12 |
601505135 |
NUT, 1/4-20 HEX Price: $3.99 |
| 13 |
601400085 |
NUT .31-18 HEX CTRLK Price: $5.99 |
| 13 |
72-5790 |
BOLT - HEX HD Price: $1.49 |
| 14 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 15 |
601505136 |
CRADLE, WELDMENT Price: $93.99 |
| 15 |
72-5590 |
DISCONTINUED Price: Call Us |
| 16 |
601000073 |
SCREW, 5/16-18X .75 HHC Price: $2.99 |
| 16 |
72-5630 |
GASKET Price: $9.39 |
| 17 |
251-349 |
BALL BEARING Price: $36.05 |
| 17 |
601505137 |
BOLT, HEX .31-18X1.62Z Price: $3.99 |
| 18 |
601505138 |
HOSE, FUEL Price: $5.99 |
| 18 |
72-5090 |
DISCONTINUED Price: Call Us |
| 19 |
601001779 |
CLAMP, HOSE Price: $3.13 |
| 19 |
72-5680 |
SPACER Price: $15.47 |
| 20 |
601505139 |
FILTER- FUEL Price: $6.99 |
| 20 |
72-5560 |
KNUCKLE KING PIN Price: $158.96 |
| 21 |
601505138 |
HOSE, FUEL Price: $5.99 |
| 21 |
93-3668 |
WASHER Price: $60.34 |
| 22 |
601400065 |
CLAMP, SCREW TYPE Price: $11.99 |
| 22 |
93-3669 |
NEEDLE BEARING Price: $160.13 |
| 23 |
601505141 |
PLATE, BOLTING SUPPORT Price: $7.99 |
| 23 |
93-3666 |
AXLE GEARBOX Price: $799.05 |
| 24 |
601505142 |
FRAME, RH. SIDE STEEL SUPPORT Price: $58.99 |
| 24 |
72-5730 |
OIL SEAL Price: $18.07 |
| 25 |
251-263 |
BEARING Price: $98.96 |
| 25 |
601505143 |
CHANNEL, FRAME SUPPORT Price: $10.99 |
| 26 |
601505144 |
FRAME, LH. SIDE STEEL SUPPORT Price: $60.99 |
| 26 |
72-5550 |
KNUCKLE CASE COVER Price: $190.19 |
| 27 |
281-10 |
PLUG Price: $14.99 |
| 27 |
601001331 |
ARM, IDLER Price: $2.47 |
| 28 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 28 |
601001694 |
BRAKE PAD Price: $1.99 |
| 29 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 29 |
601001337 |
ROD, CLUTCH LINKAGE Price: $1.52 |
| 30 |
601400075 |
NUT .38-16 HEX JAM CTR Price: $4.99 |
| 30 |
72-5540 |
DISCONTINUED Price: Call Us |
| 31 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 31 |
601505145 |
WIRE, BRAKE Price: $6.99 |
| 32 |
601001333 |
IDLER PULLEY Price: $32.99 |
| 32 |
72-5770 |
CASTELLATED NUT Price: $18.98 |
| 33 |
601505146 |
ROLLER, PINCH Price: $5.99 |
| 33 |
72-5660 |
WHEEL SHAFT WASHER Price: $14.58 |
| 34 |
601001334 |
SCREW, 3/8-16 X 1.50 Price: $1.89 |
| 34 |
72-5650 |
DISCONTINUED Price: Call Us |
| 35 |
601001330 |
SPRING, EXTENSION .38X.039X2.5 Price: $3.99 |
| 35 |
72-5570 |
DISCONTINUED Price: Call Us |
| 36 |
601001396 |
SPRING, EXTENSION .75X.069X2.0 Price: $3.99 |
| 36 |
72-5780 |
DISCONTINUED Price: Call Us |
| 37 |
281-7 |
CAP-PIPE Price: $3.69 |
| 37 |
601002081 |
BELT, 10 RIB POLY Price: $49.99 |
| 38 |
601001328 |
ARM, IDLER PIVOT Price: $3.28 |
| 38 |
93-3667 |
DISCONTINUED Price: Call Us |
| 39 |
601001329 |
BOLT Price: $3.99 |
| 40 |
601505150 |
WASHER FLAT .378X.75X.080 Price: $2.99 |
| 41 |
601505151 |
PULLEY, ENGINE Price: $23.99 |
| 42 |
601000026 |
PIN, COTTER .0625X.75LG Price: $1.71 |
| 43 |
601000533 |
WASHER, FLAT .188X .38X. Price: $2.90 |
| 44 |
601505164 |
GUIDE, BELT Price: $14.99 |
| 45 |
601400086 |
NUT .25-20 HEX CTRLOCK Price: $6.99 |
| 46 |
601400081 |
WASHER, FLAT .349X.69 Price: $6.99 |
| 47 |
601001006 |
SCREW 5/16X18 Price: $2.55 |
| 48 |
601400073 |
SCREW .25-20X0.62 HHC Price: $5.99 |
| 49 |
601001418 |
SCREW Price: $3.13 |
| 50 |
601505161 |
SPACER, DRIVE PULLEY Price: $4.99 |
| 51 |
601505162 |
BOLT, ENGINE PULEY 1/4-28X1.28 Price: $6.99 |
| 52 |
601505163 |
BOLT 5/16-18 X .865 Price: $2.99 |
