Carburetor
Parts (42)
| Ref | Part Number | Description |
|---|---|---|
| 3 | 76-0090 | HEAD Price: $161.21 |
| 4 | 76-2320 | DISCONTINUED Price: Call Us |
| 5 | 76-2330 | NUT - LOCK TOP DEFORM Price: $5.94 |
| 8 | 76-0040 | PISTON Price: $104.65 |
| 12 | 76-0050 | RING-RETAINING Price: $40.71 |
| 503478901 | 503478901 | SPACER Price: $3.99 |
| 503479001 | 503479001 | SCREW Price: $2.99 |
| 503479201 | 503479201 | SCREW Price: $2.99 |
| 503479601 | 503479601 | SCREW Price: $2.99 |
| 503479701 | 503479701 | INLET NEEDLE Price: $8.99 |
| 503480001 | 537020801 | PIN This part replaces 503480001. Price: $2.99 |
| 503480101 | 503480101 | SCREW Price: $2.99 |
| 503480501 | 503480501 | SCREW Price: $2.99 |
| 503480801 | 503994301 | SPRING This part replaces 503480801. Price: $2.99 |
| 503481101 | 503481101 | PLUG Price: $3.99 |
| 503481801 | 503481801 | SCREW Price: $2.99 |
| 503481901 | 503481901 | BUSHING Price: $5.99 |
| 503535701 | 503535701 | STRAINER Price: $3.99 |
| 503665901 | 503665901 | LEVER Price: $3.99 |
| 503755301 | 503755301 | SCREW * Price: $2.99 |
| 503974001 | 503974001 | WASHER Price: $2.99 |
| 503974301 | 503974301 | COVER Price: $5.99 |
| 537012501 | 537012501 | BALL Price: $2.99 |
| 537012601 | 537012601 | SPRING Price: $2.99 |
| 537019601 | 537019601 | SHAFT Price: $6.99 |
| 537019701 | 537019701 | SPRING THROTTLE Price: $2.99 |
| 537019801 | 537019801 | LEVER Price: $3.99 |
| 537019901 | 537019901 | THROTTLE FLAP Price: $3.99 |
| 537020001 | 537020001 | PUMP DIAPHRAGM Price: $7.99 |
| 537020101 | 537020101 | GASKET Price: $3.99 |
| 537020201 | 537020201 | COVER Price: $19.99 |
| 537020301 | 537273401 | SPRING This part replaces 537020301. Price: $4.99 |
| 537020401 | 537020401 | GASKET Price: $3.99 |
| 537020601 | 537020601 | NEEDLE HIGH SPEED Price: $3.99 |
| 537020801 | 537020801 | PIN Price: $2.99 |
| 537020901 | 537020901 | CHOKE SHAFT Price: $8.99 |
| 537021001 | 537021001 | SPRING Price: $2.99 |
| 537021601 | 537021601 | CAP Price: $2.99 |
| 537048901 | 537048901 | DIAPHRAGM Price: $11.99 |
| 537049001 | 537049001 | LEVER Price: $2.99 |
| 537127801 | 537127801 | LOW SPEED NEEDLE Price: $14.99 |
| 537370301 | 537370301 | CHOKE CAP Price: $6.99 |
