| Ref | Part Number | Description |
|---|
| 1 |
104-7201 |
NUT-HF Price: $0.69 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
119-1403-03 |
PEDAL-BRAKE Price: $112.59 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
5-0652 |
SPACER Price: $5.35 |
| 4 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 5 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 6 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 7 |
117-3214 |
CABLE-BRAKE Price: $119.83 |
| 8 |
119-1407 |
PEDAL-PARK Price: $24.62 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
119-1406 |
DETENT-BRAKE Price: $36.40 |
| 14 |
119-1405 |
ROD-BRAKE PAWL Price: $24.23 |
| 15 |
119-1414 |
PIN-COTTER, LOCKING Price: $0.54 |
| 16 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 18 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 19 |
3290-221 |
WASHER-SPRING Price: $3.12 |
| 20 |
119-1388 |
PIN-BRAKE Price: $39.02 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 24 |
323-7 |
SCREW-HH Price: $0.65 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 27 |
596133601 |
Hardware Price: $2.99 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
581023201 |
HARNESS.TEX.DASH.ELEC.REAR BAT Price: $49.99 |
| 43 |
582042802 |
Solenoids Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 582107602. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
501133701 |
HARNESS.CHASSIS.RRBATT.RDYSTRT Price: $59.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
