| Ref | Part Number | Description |
|---|
| 2 |
532008370 |
BOLT Price: $10.99 |
| 3 |
532414031 |
KIT.TILLER.8HP.GRDR&REV.GEARS This part replaces 532008547. Price: $44.99 |
| 4 |
532414031 |
KIT.TILLER.8HP.GRDR&REV.GEARS This part replaces 532008546. Price: $44.99 |
| 5 |
585695501 |
NEEDLE BEARING This part replaces 532100413. Price: $7.99 |
| 6 |
532144564 |
SPROCKET ASMBLY, TINE Price: $59.99 |
| 8 |
532004358 |
WASHER Price: $3.99 |
| 9 |
532008358 |
SHAFT.REDUCTION.TILLER Price: $14.99 |
| 10 |
532008371 |
CHAIN.ROLLER.TILLER Price: $54.99 |
| 11 |
532100371 |
SPRING-SHIFT CRT Price: $4.99 |
| 12 |
532100482 |
KIT.STEEL BALL(12 BALLS) This part replaces 532124697. Price: $4.99 |
| 13 |
532008353 |
SHIFT FORK TI Price: $22.99 |
| 14 |
532008354 |
SHAFT, SHIFT Price: $4.99 |
| 15 |
812000039 |
KLIP RING Price: $4.99 |
| 16 |
532154467 |
WASHER, SEAL (2 2) Price: $3.99 |
| 17 |
532001370 |
THRUST WASHER Price: $4.99 |
| 18 |
532004895 |
BEARING This part replaces 532124792. Price: $9.99 |
| 19 |
532150695 |
SHAFT INPUT Price: $54.99 |
| 21 |
532432060 |
KIT.TINE.SHAFT.8HP.SERVICE This part replaces 532105378. Price: $99.99 |
| 22 |
532106181 |
SPACER 1.008X1-3/4X.645 Price: $12.99 |
| 23 |
532008359 |
PINION, INPUT Price: $62.40 |
| 24 |
532005020 |
NEEDLE BRNG LT Price: $14.99 |
| 25 |
532431023 |
GASKET.GEARCASE.8HP This part replaces 532164396. Price: $22.99 |
| 26 |
532106389 |
SPACER Price: $6.99 |
| 27 |
532100433 |
GEAR, CLUSTER CRT Price: $49.99 |
| 28 |
532008357 |
REVERSE GEAR Price: $29.99 |
| 30 |
532006803 |
NEEDLE BEARING TI Price: $7.99 |
| 31 |
812000040 |
KLIP RING Price: $4.99 |
| 32 |
532008356 |
SHAFT, REVERSE IDLER Price: $17.99 |
| 33 |
532100016 |
SHAFT, REDUCTION Price: $37.99 |
| 34 |
532106392 |
SPACER.765 X 1.12 X .380. Price: $12.99 |
| 35 |
532106394 |
SPACER, GROUND DRIVE RH Price: $27.99 |
| 36 |
532100436 |
SHAFT ASSY CRT Price: $119.99 |
| 37 |
532142145 |
BRACKET ASM.SHIFT.CRT Price: $17.99 |
| 38 |
532106393 |
SPACER, GROUND DRIVE Price: $17.99 |
| 41 |
532155236 |
SEAL ASM, OIL Price: $5.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
873610700 |
NUT.ASF.HEX.7/16 Price: $5.99 |
| 45 |
594094101 |
Bolts This part replaces 817720510. Price: $1.99 |
| 47 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 48 |
532100107 |
SCREW 5/16-18X4 Price: $3.99 |
| 49 |
532106391 |
SPACER Price: $7.99 |
| 532183655 |
TRANS.SERVICE.21.CRT |
This part replaces 532170324. Price: $749.99 532183655 |
