| Ref | Part Number | Description |
|---|
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 581056301. Price: $5.99 |
| 5 |
585529804 |
DASH Price: $29.99 |
| 14 |
532441267 |
HOOD.HUSQVARNA.LT.ORANGE Price: $79.99 |
| 15 |
532406664 |
LENS.HUSQVARNA LT.LH This part replaces 532441428. Price: $14.99 |
| 18 |
584382301 |
GRILLE.SVC.HUSQVARNA.L This part replaces 532441368. Price: $54.99 |
| 25 |
532406663 |
LENS.HUSQVARNA LT.RH This part replaces 532441427. Price: $14.99 |
| 34 |
593944402 |
Engines This part replaces 580910901. Price: $74.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
583759601 |
FENDER.TEX.SRD.CRD.FRN.GUARDS This part replaces 532441369. Price: $149.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 57 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 118 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 119 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 124 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532406662 |
AIR DUCT Price: $24.99 |
| 151 |
532407807 |
BRACKET PIVOT Price: $27.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
532199472 |
CROSSMEMBER Price: $24.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 180 |
583902701 |
WELDMENT.CHASSIS.TEX.CRD.GEN.2 Price: $139.99 |
| 182 |
532407176 |
DASH.LOWER.PREDATOR LT Price: $69.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 191 |
583358401 |
INSERT.REFLECTIVE.RH. This part replaces 532416501. Price: $11.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 198 |
532441552 |
INDICATOR.DECK.LIFT.RED Price: $11.99 |
| 199 |
583371401 |
PLATE.DECKLIFT.SRD This part replaces 532418739. Price: $7.99 |
| 202 |
532441342 |
VENT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 203 |
532406671 |
VENT SIDE HOOD This part replaces 532441343. Price: $8.99 |
| 204 |
532441375 |
SUBASM.TOP.VENT.HUSQ.LT Price: $17.99 |
| 205 |
532441344 |
SKIRT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 206 |
532441345 |
SKIRT.SIDE.HUSQVARNA.LT.LEFT Price: $11.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532407881 |
TRIM.HUSQ LT.668 This part replaces 532441374. Price: $19.99 |
| 239 |
532404883 |
IS ITO Price: $5.99 |
| 282 |
532414110 |
CLIP.RETAINER.CONSOLE.LT.HUSQ Price: $2.99 |
| 283 |
532447212 |
CONSOLE.DECKLIFT.CRDII.498 Price: $129.99 |
| 284 |
532447220 |
CONSOLE.PEDAL.HYDRO Price: $54.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 297 |
532406665 |
INSERT REFLECTIVE Price: $6.99 |
| 303 |
587493101 |
SHIELD.LWR.LH.LT.30DECK.CRDSRD This part replaces 587493102. Price: $14.99 |
| 304 |
587492702 |
SHIELD.LWR.RH.LT30DECK.PNT.BLK Price: $14.99 |
| 307 |
587494501 |
SHIELD.UPPER.CRD.SRD.ISO Price: $22.99 |
| 308 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 309 |
597316401 |
Plates This part replaces 581328911. Price: $129.99 |
| 319 |
581313906 |
LEVER.BAG.CRDII.ANTIROTATION Price: $11.99 |
| 334 |
583564401 |
BRACKET.ENGINE. This part replaces 532442537. Price: $8.99 |
| 338 |
583510201 |
BOLT.SHOULDER.5/16-18.X.88 This part replaces 532436640. Price: $4.99 |
| 339 |
583510301 |
SUBASM.BAGGER.FULL.LVER.(2 2) This part replaces 532436641. Price: $5.99 |
| 340 |
581328906 |
BACKPLATE.ASM.TXCRDII.ANTIROTA This part replaces 581329001. Price: $109.99 |
| 342 |
582826802 |
SUPPORT.PNT.FENDER.CRD.TEX This part replaces 532435938. Price: $17.99 |
| 343 |
582671501 |
CLIP This part replaces 532440749. Price: $2.99 |
| 347 |
583566701 |
HITCH.TOW.TEX.CRD.GEN.2 This part replaces 532442887. Price: $12.99 |
| 349 |
583509701 |
LRVB.FUEL.TANK.SUPPORT.BRACKET This part replaces 532436606. Price: $5.99 |
| 366 |
581314602 |
BRACKET.RH.FRONT.BAGGER.BLACK Price: $19.99 |
| 367 |
581314502 |
BRACKET.LH.FRONT.BAGGER.BLACK Price: $19.99 |
| 372 |
592807801 |
BOLT CUP HEAD SQUARE NECK 1/4- This part replaces 539109800. Price: $2.99 |
| 373 |
586299803 |
REINFORCEMENT BACKPLATE. CRD B Price: $59.99 |
| 375 |
586908201 |
BUMPER CLIP-ON. DASH 1" Price: $3.99 |
