| Ref | Part Number | Description |
|---|
| 1 |
47-3380-01 |
CONTROL TOWER ASM Price: $407.03 |
| 1 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 2 |
47-3680-01 |
UPPER CONTROL TOWER ASM Price: $528.76 |
| 2 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 3 |
47-3820-03 |
COVER-COLUMN Price: $79.97 |
| 3 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 4 |
47-3810 |
LEVER-VALVE Price: $60.07 |
| 4 |
532008156 |
FOOT PEDAL COVER Price: $2.64 |
| 5 |
3-0631 |
BALL-GRIP Price: $10.76 |
| 5 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 6 |
47-3450 |
PIVOT PIN Price: $54.81 |
| 6 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 7 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 7 |
819131016 |
WASHER Price: $2.99 |
| 8 |
47-3620 |
BLOCK-PIVOT, LEVER Price: $54.93 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 9 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 10 |
47-3880-03 |
CONTROL LINKAGE ASM Price: $260.93 |
| 10 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 11 |
3217-8 |
NUT-HEX Price: $1.34 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 12 |
47-3630 |
ROD-LINKAGE, CONTROL Price: $104.04 |
| 12 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY Price: $21.38 |
| 13 |
47-3460 |
U-BOLT Price: $29.53 |
| 13 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 14 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 15 |
532133332 |
ARM, BRAKE ASMBLY Price: $6.71 |
| 16 |
52-5990 |
HYD HOSE Price: $381.48 |
| 16 |
819251816 |
WASHER T Price: $4.99 |
| 17 |
52-5991 |
HYD HOSE Price: $322.07 |
| 17 |
812000034 |
Ring, Klip Truarc #5304-75 Price: $2.99 |
| 18 |
353-819 |
COUPLER-BODY Price: $156.66 |
| 18 |
532151332 |
SPRING, BRAKE ROD Price: $4.99 |
| 19 |
353-820 |
COUPLER-TIP Price: $84.94 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 20 |
49-8180 |
DISCONTINUED Price: $15.10 |
| 20 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 21 |
47-3770 |
DECAL-MANUAL, OWNER Price: $25.33 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 22 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 26 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 27 |
532127369 |
LINK.MOWER.REAR Price: $9.99 |
| 28 |
532140776 |
REAR MOWER LIFT ASSY Price: $40.26 |
| 29 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 30 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 31 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
