| Ref | Part Number | Description |
|---|
| 1 |
3-8394 |
DISCONTINUED Price: Call Us |
| 1 |
532428048 |
CHASSIS.WLD.26".LRV Price: $129.99 |
| 2 |
3-7138 |
DISCONTINUED Price: Call Us |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 4 |
325-3 |
SCREW-HH Price: $1.49 |
| 5 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 5 |
532428110 |
STRAP.CROSS.FRICTION.DRIVE Price: $9.99 |
| 6 |
322-10 |
SCREW-HH Price: $0.70 |
| 6 |
532428109 |
COVER, FRICTION DRIVE Price: $14.99 |
| 7 |
20-4890 |
DISCONTINUED Price: Call Us |
| 7 |
532428040 |
PLATE, ENGINE Price: $24.99 |
| 8 |
3210-3 |
SCREW-HH Price: $5.29 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 9 |
532428856 |
BRACKET, STEERING SUPPORT Price: $4.99 |
| 10 |
4-2320 |
DISCONTINUED Price: Call Us |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $14.99 |
| 11 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 11 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $4.99 |
| 12 |
117127 |
TIRE (16 X 6.5-8) 2-PLY -2 WHEEL AXEL This part replaces 231-39. Price: $107.13 |
| 12 |
532428248 |
BOOT, DUST LRV (2 2) Price: $11.99 |
| 13 |
3-2889 |
DISCONTINUED Price: Call Us |
| 13 |
532436496 |
FOOTREST.AESTHETIC.WE.GRN.LRV Price: $32.99 |
| 14 |
532428250 |
STRUCTURE, FOOT REST Price: $49.99 |
| 15 |
3-8014 |
AXLE SHAFT Price: $49.11 |
| 15 |
532428249 |
SUPPORT, FOOT REST Price: $24.99 |
| 16 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 16 |
532436497 |
FENDER.CNTRL.PNL.WE.GRN.LRV Price: $74.99 |
| 17 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 17 |
532428348 |
GUARD.ENGINE.LRV Price: $17.99 |
| 18 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 19 |
242-39 |
WHEEL ASM Price: $244.32 |
| 19 |
532428986 |
KEEPER, BELT Price: $6.99 |
| 20 |
242-33 |
DISCONTINUED Price: Call Us |
| 20 |
532428046 |
BRACKET, BATTERY LRV Price: $3.99 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 21 |
532429815 |
LEVER, SWITCH Price: $2.99 |
| 22 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 22 |
532428826 |
CABLE.ASM.CLUTCH.W/BRACKET Price: $74.99 |
| 23 |
3-6506 |
DISCONTINUED Price: Call Us |
| 23 |
532149846 |
KNOB.OVAL.CUSTOM.BLACK Price: $5.99 |
| 24 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 24 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 25 |
5-0460 |
STRG SWAGED CABLE ASM Price: $96.86 |
| 25 |
872140424 |
BOLT.CARRIAGE Price: $2.99 |
| 26 |
3-8011 |
DISCONTINUED Price: Call Us |
| 26 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 27 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
532430087 |
SPACER.ENGINE.B&S.LRVA Price: $2.99 |
| 28 |
242-32 |
LUG NUT Price: $4.77 |
| 28 |
580747201 |
HUB.FRICTION.COMPOSITE SUBASM This part replaces 532428301. Price: $34.99 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 29 |
532430817 |
BOLT, SCKT HD 3/8-24 X 1 .25 Price: $2.99 |
| 30 |
32146-1 |
DISCONTINUED Price: Call Us |
| 30 |
532430470 |
BEARING.BALL.689ZZ Price: $4.99 |
| 31 |
5-5560 |
DISCONTINUED Price: Call Us |
| 31 |
532437322 |
SPACER.NEUTRAL Price: $2.99 |
| 32 |
5-1257 |
DISCONTINUED Price: Call Us |
| 32 |
583608601 |
BOLT.HEX.WSH.HD.6/16-18 X 3/8 This part replaces 817490506. Price: $2.99 |
| 33 |
5-2106 |
PVT CSTR/SFT WA*RO Price: $291.44 |
| 33 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 34 |
32128-13 |
NUT-HF Price: $1.79 |
| 34 |
532121250 |
SPRING Price: $3.99 |
| 35 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 35 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 36 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 36 |
532127018 |
BOLT,SHOULD Price: $3.99 |
| 37 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 37 |
819171912 |
WASHER Price: $3.99 |
| 38 |
3-6493 |
DISCONTINUED Price: Call Us |
| 38 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 39 |
3217-6 |
NUT-HEX Price: $1.19 |
| 39 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 40 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 40 |
532121248 |
BUSHING Price: $3.99 |
| 41 |
32121-48 |
PIN-SPRING Price: $0.61 |
| 41 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 42 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 43 |
20-4900 |
DISCONTINUED Price: Call Us |
| 43 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 44 |
3-7993 |
DISCONTINUE Price: Call Us |
| 44 |
532440691 |
SEAT.SUBASY.OPP.WEEDEATER.LRVA Price: $129.99 |
| 45 |
5-5540 |
DISCONTINUED Price: Call Us |
| 45 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 46 |
325-9 |
SCREW-HH Price: $1.87 |
| 46 |
817490508 |
SCREW LT Price: $3.99 |
| 47 |
322-13 |
SCREW-HH Price: $2.73 |
| 47 |
532086777 |
Screw, Hex, Washer Hd., Slotted, Thd. Cutting #10-24 x 1/2 Type D (AYP part number) Price: $1.99 |
| 48 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 48 |
532408981 |
BEARING FLANGE BALL Price: $5.99 |
| 49 |
3290-239 |
DISCONTINUED Price: Call Us |
| 49 |
817060516 |
SCREW 5/16-18X1 Price: $3.99 |
| 50 |
3-6501 |
DISCONTINUED Price: Call Us |
| 50 |
532165492 |
BOLT.SHOULDER.5/16-18X Price: $3.99 |
| 51 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
