| Ref | Part Number | Description |
|---|
| 1 |
576480002 |
PLATE, HEIGHT INNER ORG Price: $84.99 |
| 1 |
68-5370 |
DECAL Price: $6.21 |
| 1 |
925-3141 |
Ammeter This part replaces 725-3023. Price: $55.06 |
| 2 |
576480102 |
PLATE, HEIGHT OUTER ORG Price: $59.99 |
| 2 |
66-9760 |
DISCONTINUED Price: Call Us |
| 2 |
KB-H1940-83000 |
GAUGE-TEMPERATURE Not Available This part replaces KB-19488-83030. Price: |
| 3 |
593634102 |
PLATE.PNT.PILLOW.BLOCK.EDIP This part replaces 525822201. Price: $2.99 |
| 3 |
725-3058 |
HOURMETER Not Available Price: |
| 3 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 4 |
21-9260 |
COVER-DUST Price: $8.19 |
| 4 |
576646701 |
PLATE, SPRING ANCHOR Price: $7.99 |
| 4 |
KB-15521-65950 |
LAMP Not Available Price: |
| 5 |
576485802 |
Spacers This part replaces 576485801. Price: $3.99 |
| 5 |
82-8660-01 |
COVER-TOWER This part replaces 82-8660. Price: $30.45 |
| 6 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 6 |
576623102 |
Spacers This part replaces 576623101. Price: $3.99 |
| 6 |
725-3125 |
LAMP Not Available Price: |
| 7 |
576623002 |
Spacers This part replaces 576623001. Price: $2.99 |
| 7 |
67-8690-03 |
SUPPORT-COLUMN This part replaces 67-8690. Price: $81.08 |
| 7 |
925-0893 |
Switch, PTO This part replaces 725-0893. Price: $72.43 |
| 8 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 8 |
596839401 |
Spacers This part replaces 510362501. Price: $5.99 |
| 8 |
736-3003 |
FLAT WASHER .531X.688X.054 Not Available Price: |
| 9 |
510408302 |
Pedals This part replaces 510408301. Price: $27.99 |
| 9 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 9 |
77-3120-01 |
BRACKET-MOUNTING, COLUMN This part replaces 77-3120. Price: $49.33 |
| 10 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 10 |
80-2960 |
SPACER-TOWER Price: $11.13 |
| 11 |
510406802 |
Latch This part replaces 510406801. Price: $19.99 |
| 11 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 11 |
KB-66711-55240 |
IGNITION KEY Not Available This part replaces KB-66711-55140. Price: |
| 12 |
576638901 |
LEVER, TRANSPORT RELEASE Price: $19.99 |
| 12 |
725-3087 |
LIGHT SWITCH Not Available Price: |
| 12 |
82-8760 |
ELBOW-HYD Price: $59.61 |
| 13 |
237-30 |
O-RING Price: $2.50 |
| 13 |
583623801 |
SHAFT.DECK.LIFT.FT This part replaces 576479201. Price: $219.99 |
| 13 |
KB-H1550-64600 |
REGULATOR Not Available This part replaces KB-15533-64600. Price: |
| 14 |
576479901 |
SHAFT, LIFT LEFT REAR Price: $89.99 |
| 14 |
63-8970 |
HOSE-HYD Price: $162.31 |
| 14 |
925-3090 |
CIRCUIT BREAKER Not Available This part replaces 725-3090. Price: |
| 15 |
576479401 |
SHAFT, LIFT RIGHT REAR Price: $89.99 |
| 15 |
70-1390 |
SLEEVE-PROTECTIVE Price: $42.56 |
| 15 |
731-3038 |
BRACKET-CIRCUIT BREAKER Not Available Price: |
| 16 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 16 |
510089401 |
BUSHING, FLANGE 1.25 X 1.0 Price: $17.99 |
| 16 |
710-0606 |
Screw, Hex Cap, 1/4-20 X 1.50 Lg Price: $4.67 |
| 17 |
510023902 |
BLOCK, PILLOW Price: $11.99 |
| 17 |
70-1380 |
SLEEVE-PROTECTIVE Price: $42.56 |
| 17 |
712-3052 |
LOCK NUT #4-40 Not Available Price: |
| 18 |
576676601 |
SPRING, EXTENSION Price: $22.99 |
| 18 |
68-9730 |
HOSE-STEERING, HYD Price: $116.90 |
| 18 |
710-3112 |
HEX SCREW HD MACH Not Available Price: |
| 19 |
510376601 |
SPRING, TORSION Price: $2.99 |
| 19 |
68-9720 |
HOSE-STEERING, HYD Price: $118.16 |
| 19 |
725-3066 |
SWITCH Not Available Price: |
| 20 |
237-22 |
O-RING Price: $2.43 |
| 20 |
510089802 |
Rods This part replaces 510089801. Price: $119.99 |
| 20 |
629-0739 |
WIRE ASSEMBLY (BLACK) (#6X14) Not Available This part replaces 725-0994. Price: |
| 21 |
576622602 |
Strap This part replaces 576622601. Price: $299.99 |
| 21 |
82-8770 |
ELBOW-HYD Price: $73.15 |
| 21 |
KB-68371-51210 |
Pump, Electric Fuel Price: $437.54 |
| 22 |
510106501 |
ASSEMBLY, STRUT Price: $99.99 |
| 22 |
63-8980 |
HOSE-HYD Price: $160.86 |
| 22 |
925-0894 |
RELAY Not Available This part replaces 725-0894. Price: |
| 23 |
596919401 |
Pins This part replaces 510090101. Price: $4.99 |
| 23 |
63-8990 |
HOSE-HYD Price: $57.67 |
| 23 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 24 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 24 |
510016502 |
Pins This part replaces 510016501. Price: $7.99 |
| 24 |
736-0222 |
Washer, External Lock, 1/4 Price: $5.07 |
| 25 |
108-6557 |
STEER VALVE AND COLUMN ASM This part replaces 92-7308. Price: $1,800.82 |
| 25 |
515988202 |
Pins This part replaces 515988201. Price: $37.99 |
| 25 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 26 |
576485602 |
Pins This part replaces 576485601. Price: $4.99 |
| 26 |
712-3006 |
HEX NUT Price: $4.05 |
| 27 |
323-6 |
SCREW-HH Price: $0.66 |
| 27 |
539124704 |
COTTER PIN 1/8 X 2 This part replaces 539102889. Price: $2.99 |
| 27 |
925-3060 |
Brake Switch 1 This part replaces 725-3060. Price: $35.31 |
| 28 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 28 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 28 |
735-3006 |
BOOT Not Available Price: |
| 29 |
596789601 |
Bolts This part replaces 525828901. Price: $3.99 |
| 29 |
725-3019 |
CABLE ASSEMBLY-TAIL LAMP Not Available Price: |
| 29 |
80-2940-03 |
PLATE-PIVOT This part replaces 80-2940. Price: $40.35 |
| 30 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 30 |
574210602 |
Screws This part replaces 574210601. Price: $2.99 |
| 30 |
725-3020 |
BULB Not Available Price: |
| 31 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 31 |
525612802 |
Screws This part replaces 525612801. Price: $2.99 |
| 31 |
725-3018 |
Lens Assy, Tail Light Price: Call Us |
| 32 |
576621602 |
Screws This part replaces 576621601. Price: $1.99 |
| 32 |
732-3011 |
SPRING-HEA Not Available Price: |
| 32 |
80-2980 |
BOSS - TILT STEERING Price: $48.89 |
| 33 |
577098301 |
HHFS 3/8-16 X 2.25 GD 8 This part replaces 574496901. Price: $5.99 |
| 33 |
925-0222 |
Head Light This part replaces 725-0222. Price: $51.68 |
| 34 |
108-6092 |
LEVER-STEERING, TILT This part replaces 93-1353. Price: $49.30 |
| 34 |
525822101 |
HHFS 3/8-16 X 3.5 GD 5 ZD Price: $4.99 |
| 34 |
703-0166 |
RETAINER-HEADLAMP Not Available Price: |
| 35 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 35 |
525464701 |
HHFS 5/16-18 X 3/4 Price: $2.99 |
| 36 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 36 |
525829001 |
HHFS 5/8-11 X 3.0 GD 8 ZD Price: $27.99 |
| 37 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 37 |
82-8650 |
CLAMP-COLUMN Price: $16.37 |
| 38 |
576479002 |
Hardware This part replaces 576479001. Price: $5.99 |
| 38 |
82-9010 |
DISC-FRICTION Price: $15.53 |
| 39 |
516035502 |
Bolts This part replaces 516035501. Price: $4.99 |
| 39 |
80-2930 |
WASHER-FLAT Price: $5.00 |
| 40 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 40 |
80-2880 |
BRACKET-TILT Price: $18.75 |
| 41 |
32128-20 |
NUT-HF Price: $0.99 |
| 41 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 42 |
3218-7 |
NUT-JAM Price: $3.86 |
| 42 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 43 |
322-4 |
SCREW-HH Price: $0.35 |
| 43 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 44 |
532429164 |
NUT.PUSH.625 This part replaces 539109304. Price: $4.99 |
| 44 |
82-8940 |
DECAL-STEERING, TILT Price: $24.33 |
| 45 |
32144-21 |
SCREW Price: $0.20 |
| 45 |
525829102 |
Nuts This part replaces 525829101. Price: $2.99 |
