| Ref | Part Number | Description |
|---|
| 1 |
133-0751-03 |
COVER-SCREEN Price: $93.60 |
| 1 |
631708 |
SHAFT & LEV Price: Call Us |
| 1 |
898000129 |
Nut, Flange 5/16-18 (AYP part number) Price: $5.99 |
| 2 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 2 |
532440452 |
SHIELD.PNT.SIDE.OUTER.LH.ORANG This part replaces 532104086. Price: $14.99 |
| 2 |
631045 |
RET SPRING Price: Call Us |
| 3 |
132-3668 |
SEAL-COVER, SHORT SIDE Price: $4.11 |
| 3 |
532008393 |
Pin, Stake, Depth (AYP part number) Price: $17.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
132-3669 |
SEAL-COVER, LONG SIDE Price: $3.37 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 4 |
812000036 |
Ring, Klip (AYP part number) Price: $3.99 |
| 5 |
132-3670-03 |
STRAP-ROOF, LONG Price: $18.27 |
| 5 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 6 |
132-3671-03 |
STRAP-ROOF, SHORT Price: $11.73 |
| 6 |
532008394 |
Spring (AYP part number) Price: $3.99 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
104-7201 |
NUT-HF Price: $0.69 |
| 7 |
31836 |
SHAFT & LEV Price: $5.21 |
| 7 |
532008392 |
Bracket, Latch (AYP part number) Price: $3.99 |
| 8 |
532109230 |
Spring, Depth Stake (AYP part number) Price: $3.99 |
| 8 |
631553 |
SCREEN Price: Call Us |
| 9 |
532124736 |
Shield, Tine (AYP part number) Price: $3.33 |
| 9 |
630758 |
SHUTTER Price: $1.20 |
| 10 |
631562 |
ADJ SCREW Price: $3.74 |
| 10 |
872140508 |
Bolt, Carriage 5/16-18 UNC x 1 (AYP part number) Price: $2.99 |
| 11 |
630738 |
SPRING Price: $1.25 |
| 11 |
873220500 |
Nut, Hex 5/16-18 (AYP part number) Price: $3.99 |
| 11A |
630738 |
SPRING Price: $1.25 |
| 12 |
630739 |
WASHER Price: $1.25 |
| 12 |
810040500 |
Washer, Lock 5/16 (AYP part number) Price: $2.99 |
| 12A |
630739 |
WASHER Price: $1.25 |
| 13 |
630740 |
O RING Price: $1.49 |
| 13 |
872110510 |
Bolt, Carriage 5/16-18 x 1-1/4 (AYP part number) Price: $3.99 |
| 13A |
630740 |
O RING Price: $1.49 |
| 14 |
581813501 |
BRACKET.TINE.SHIELD.TILLER.BLA This part replaces 532124311. Price: $9.99 |
| 14 |
631761 |
ADJ SCREW Price: Call Us |
| 15 |
532195795 |
SHIELD.SIDE.OUTER.RH.BLACK This part replaces 532104101. Price: $9.99 |
| 15 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 15A |
630748 |
WELCH PLUG Price: $1.17 |
| 16 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 16 |
630953 |
PUMP ELEMENT Price: $6.03 |
| 17 |
632259A |
GASKET This part replaces 631554. Price: Call Us |
| 17 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 18 |
631049 |
SPRING Price: $1.20 |
| 18 |
872040410 |
Bolt, Carriage 1/4-20 x 1-1/4 Gr. 5 (AYP part number) Price: $3.99 |
| 19 |
532102701 |
Grip (AYP part number) Price: $3.99 |
| 19 |
630742 |
GASKET Price: $1.25 |
| 20 |
631707 |
INLET NEEDLE Price: Call Us |
| 20 |
873220600 |
Nut, Hex 3/8-16 (AYP part number) Price: $3.99 |
| 21 |
532102156 |
STAKE.DEPTH.16.CRT.BLACK This part replaces 532144437. Price: $22.99 |
| 21 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 22 |
630978 |
DIAPHRAGM Price: $4.49 |
| 22 |
874930632 |
Bolt, Hex 3/8-16 x 2 (AYP part number) Price: $3.99 |
| 23 |
532004440 |
Hinge (AYP part number) Price: $3.99 |
| 23 |
630751 |
COVER Price: $8.60 |
| 24 |
650545 |
SCREW Price: $1.20 |
| 24 |
872140404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 (AYP part number) Price: $3.99 |
| 25 |
532006712 |
VINYL CAP This part replaces 532124717. Price: $3.99 |
| 25 |
631555 |
VALVE Price: Call Us |
| 26 |
532109227 |
Pad, Idler (AYP part number) Price: $2.99 |
| 26 |
631709 |
VALVE COVER Price: Call Us |
| 27 |
532124714 |
Shield, Leveling (AYP part number) Price: $3.33 |
| 28 |
532120588 |
Pin, Hinge (AYP part number) Price: $3.99 |
| 29 |
532124737 |
Shield, Side (AYP part number) Price: $3.33 |
| 31 |
650699 |
SCREW Price: $1.17 |
| 35 |
630735 |
SPRING Price: $1.25 |
