| Ref | Part Number | Description |
|---|
| 1 |
513241901 |
NUT This part replaces 544259901. Price: $3.99 |
| 1 |
925-04514 |
BATTERY Not Available This part replaces 725-3174. Price: |
| 1 |
98-7430 |
O-RING Price: $1.95 |
| 2 |
107-9075 |
PLUG-FILLER, OIL This part replaces 98-9449. Price: $7.25 |
| 2 |
506689401 |
KEY This part replaces 544260001. Price: $2.99 |
| 2 |
725-3220 |
POITIVE BATTERY CABLE Not Available Price: |
| 3 |
544260101 |
ROTOR Price: $44.99 |
| 3 |
725-3221 |
NEGATIVE BATTERY CABLE Not Available Price: |
| 3 |
98-9455 |
NUT-CAP Price: $4.77 |
| 4 |
574818701 |
COIL This part replaces 505183501. Price: $129.99 |
| 4 |
710-3083 |
Screw, Hex Cap, 5/16-18 X 1.38 Lg Price: $3.94 |
| 4 |
98-9454 |
GASKET Price: $1.43 |
| 5 |
544260501 |
TUBE-B Price: $2.99 |
| 5 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 5 |
98-9492 |
JOINT-PIPE, BREATHER Price: $9.68 |
| 6 |
512444001 |
CAP This part replaces 544260301. Price: $5.99 |
| 6 |
703-1823-0716 |
BATTERY HOLD DOWN (CUB YELLOW-99) Not Available This part replaces 703-1823. Price: |
| 6 |
98-9491 |
PIPE-BREATHER Price: $12.92 |
| 7 |
505183601 |
SPRING Price: $1.06 |
| 7 |
731-3105 |
TRAY, BATTERY Not Available Price: |
| 7 |
98-9364 |
SCREW (WITH WASHER) Price: $0.32 |
| 8 |
544260601 |
GROMMET Price: $2.99 |
| 8 |
759-3653 |
CAP-BATTERY VENT Not Available Price: |
| 8 |
98-9490 |
SHIELD-OIL, BREATHER Price: $1.28 |
| 9 |
506615101 |
SPARK PLUG NGK CMR7H This part replaces 544260901. Price: $8.99 |
| 9 |
729-0207 |
FUSE HOLDER Not Available Price: |
| 9 |
98-9488 |
PLATE-ELEMENT, BREATHER Price: $1.33 |
| 10 |
544362901 |
RP TUBE-A Price: $2.99 |
| 10 |
925-1381 |
Fuse, 20 Amp This part replaces 725-1381. Price: $5.38 |
| 10 |
98-9493 |
ELEMENT-BREATHER Price: $6.10 |
| 11 |
506745701 |
BOLT This part replaces 544257501. Price: $2.99 |
| 11 |
729-0209 |
CLIP-FUSE HLD MTG Not Available Price: |
| 11 |
98-9489 |
PLATE-ELEMENT, BREATHER Price: $7.89 |
| 12 |
505183701 |
CORD Price: $5.99 |
| 12 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 12 |
98-9615 |
GASKET-COVER, HEAD Price: $20.34 |
| 13 |
506745701 |
BOLT This part replaces 544259001. Price: $2.99 |
| 13 |
925-1375 |
RELAY Not Available This part replaces 725-1375. Price: |
| 13 |
98-9614 |
CYLINDER HEAD COVER ASM Price: $256.63 |
| 14 |
929-3080 |
VOLTAGE SENSOR W/ADAPTER HARNESS Not Available This part replaces 725-3165. Price: |
| 15 |
736-0722 |
Washer, Lock, #10 Price: $5.81 |
| 16 |
712-0121 |
Nut, Hex, #10-24 Price: $3.75 |
| 17 |
710-3175 |
SCREW M8-1.25 x 14MM GR8.8 Not Available Price: |
| 18 |
725-3218 |
Main Harness Price: Call Us |
| 19 |
725-3147 |
QUICK CONNECT LUG Not Available Price: |
| 20 |
712-3077 |
HEX NUT M8X1.25 GR8.8 Not Available Price: |
