| Ref | Part Number | Description |
|---|
| 1 |
5-1106-01 |
HINGE-BALL, RH This part replaces 5-1106. Price: $66.76 |
| 1 |
532186968 |
NEEDS DESCRIPTION Price: Call Us |
| 2 |
5-1104-01 |
SOCKET ASM-HINGE,RH This part replaces 5-1104. Price: $165.99 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
11-9970 |
CENTER FRAME W.A. Price: $2,271.14 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
4-8569 |
DISCONTINUED Price: Call Us |
| 5 |
532184579 |
TUBE EXHAUST LH Price: $49.99 |
| 6 |
32153-5 |
NUT-HEX Price: $1.59 |
| 6 |
532184580 |
EXHAUST.TUBE.RH.KAWA Price: $49.99 |
| 7 |
5-1116-01 |
DISCONTINUED This part replaces 5-1116. Price: Call Us |
| 8 |
325-6 |
SCREW-HH Price: $1.42 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
12-0030 |
DISCONTINUED Price: Call Us |
| 10 |
12-0010 |
U BOLT W.A. Price: $81.76 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
6-0860 |
TRLG&3UNIT DRAWBAR WA*R Price: $840.26 |
| 12 |
5-1108 |
BOLT-HINGE CLAMP Price: $42.89 |
| 13 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 14 |
5-1107-01 |
HINGE CAP ASM This part replaces 5-1107. Price: $161.71 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
5-1103-01 |
SOCKET ASM-HINGE, LH This part replaces 5-1103. Price: $146.47 |
| 16 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 17 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 19 |
325-5 |
SCREW-HH Price: $1.20 |
| 20 |
5-1092 |
DISCONTINUED Price: Call Us |
| 21 |
5-1093 |
DISCONTINUED Price: Call Us |
| 22 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 23 |
5-1094 |
FORK *R Price: $31.80 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
5-9390 |
LIFT HANDLE *B Price: $45.72 |
| 25 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 25 |
532187766 |
CONTROL, CHOKE, 37", PUSH This part replaces 532191717. Price: $17.99 |
| 26 |
287-2 |
DISCONTINUED Price: Call Us |
| 27 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 28 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 29 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
5-2942 |
SHACKLE Price: $16.99 |
| 31 |
325-4 |
SCREW-HH Price: $0.95 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
12-0120 |
DISCONTINUED Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
5-1091 |
SPACER Price: $4.98 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 35 |
3-7254-01 |
DRAW BAR BRACKET This part replaces 3-7254. Price: $227.92 |
| 36 |
325-10 |
SCREW-HH Price: $1.82 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 38 |
5-1111 |
CASTOR WHEEL BUSHING Price: $10.11 |
| 39 |
5-1112 |
DRAWBAR PIN Price: $9.77 |
| 40 |
4-8669 |
DISCONTINUED Price: Call Us |
| 41 |
12-0060 |
DISCONTINUED Price: Call Us |
| 42 |
5-1105-01 |
HINGE-BALL, LH This part replaces 5-1105. Price: $57.25 |
| 43 |
5-1087 |
DISCONTINUED Price: Call Us |
| 44 |
3290-256 |
PIN-HAIR Price: $1.01 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
4-8629 |
DISCONTINUED Price: Call Us |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
5-1085 |
DRAWBAR COUPLER *R Price: $231.54 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 47 |
5-1086 |
SPRING REBOUND PIN Price: $86.79 |
| 48 |
5-1084 |
DISCONTINUED Price: Call Us |
| 49 |
5-1088 |
DISCONTINUED Price: Call Us |
| 50 |
3272-38 |
PIN-COTTER Price: $3.05 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
