| Ref | Part Number | Description |
|---|
| 1 |
532415539 |
PANEL.CONTROL.PNT.BLACK This part replaces 585198802. Price: $19.99 |
| 1 |
66-6370 |
LIFT ARM ASM This part replaces 21-3100. Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
584809001 |
BAIL.CONTROL.INTERLOCK.SNOW Price: $8.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
585004703 |
ARM.IMPELLER.ROD. Price: $2.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
539990072 |
HCS 1/4C X 5/8 This part replaces 874780410. Price: $1.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
532421613 |
SPACER.CONTROL.LEVER Price: $2.99 |
| 8 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 8 |
532088349 |
NUT Price: $3.99 |
| 9 |
532414281 |
RED KNOB SHIFTER Price: $8.99 |
| 9 |
66-7150 |
ARM-PUSH, RH This part replaces 21-2910. Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
532414280 |
KNOB LEVER, BLACK Price: $3.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 12 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 12 |
819131316 |
WASHER Price: $2.99 |
| 13 |
256-126 |
BUSHING Price: $9.36 |
| 13 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $3.99 |
| 14 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 15 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 16 |
324-5 |
SCREW-HH Price: $0.54 |
| 17 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 18 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 19 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 20 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 21 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 22 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 23 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 24 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 25 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 26 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 27 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 28 |
324-6 |
SCREW-HH Price: $0.81 |
| 29 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 30 |
86-8100-01 |
BALL JOINT ASM This part replaces 21-0160. Price: $137.53 |
| 31 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 32 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 33 |
61-3610 |
WARNING DECAL This part replaces 21-3970. Price: $16.67 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
5-2942 |
SHACKLE Price: $16.99 |
| 36 |
283-10 |
PIN-CLEVIS Price: $7.43 |
