| Ref | Part Number | Description |
|---|
| 1 |
720-04167 |
Grip, Handle, 26 x 16 x 630 Price: $8.70 |
| 2 |
749-04811 |
Handle, Upper Price: $24.33 |
| 3 |
749-04812 |
Handle, Middle Price: $16.19 |
| 4 |
720-04168 |
Knob Price: $3.86 |
| 5 |
749-04813 |
Handle, Lower, TBR16 Price: $26.12 |
| 5 |
749-04814 |
Handle, Lower, TBR18 Price: $27.03 |
| 6 |
710-05321 |
Bolt, M6x35gb/T12 Price: $3.63 |
| 7 |
711-05530 |
Shaft, Rear, TBR16 Price: $21.23 |
| 7 |
711-05532 |
Shaft, Rear, TBR18 Price: $21.94 |
| 8 |
712-04292 |
Nut, M8, Gb/T6172.2 Price: $3.28 |
| 9 |
736-04563 |
Washer, 17 x 8.2 x 1.2 Price: $3.49 |
| 10 |
711-05534 |
Pin, TBR16 Price: $26.12 |
| 10 |
711-05535 |
Pin, TBR18 Price: $22.62 |
| 11 |
710-05322 |
Screw, M8-16gbt70.2 Price: $3.49 |
| 12 |
787-01959 |
Bracket, Rear, LH, Price: $16.75 |
| 13 |
987-01960 |
ADJUSTMENT ROD BRACKET Not Available Price: |
| 14 |
734-04605 |
Wheel, Rear Price: $21.55 |
| 15 |
736-04564 |
Washer, 17 x 8.2 x 1.2 Price: $3.49 |
| 16 |
736-04565 |
Washer, Gb/T955 Price: $3.24 |
| 17 |
736-04566 |
Washer, 20 x 13 x 1 Price: $3.21 |
| 18 |
710-05323 |
Bolt, M8 x 24 Price: $3.24 |
| 19 |
787-01964 |
Bracket, Lower Blade, TBR16 Price: $67.77 |
| 19 |
787-01966 |
Bracket, Lower Blade, TBR18 Price: $76.39 |
| 20 |
712-04293 |
Nut, M8 x 1 Price: $3.75 |
| 21 |
732-04854 |
SPACER-65 MM Not Available Price: |
| 22 |
710-05324 |
Bolt, M8 x 1 x 65 Price: $3.70 |
| 23 |
736-04567 |
Washer, 25 x 6.5 x 1.5 Price: $3.24 |
| 24 |
710-05325 |
Bolt, M6x20, Gb/T5780 Price: $3.49 |
| 25 |
731-08253 |
Hub Cap Price: $7.20 |
| 26 |
734-04606 |
Wheel, Complete Price: $35.26 |
| 27 |
787-01968 |
Bracket, Black Price: $17.48 |
| 28 |
736-04568 |
Washer, Spacer, Gb/T7244 Price: $3.13 |
| 29 |
787-01972 |
Bracket, Support, LH Price: $24.63 |
| 30 |
736-04569 |
Washer, 20x10.2x1.4 Price: $3.13 |
| 31 |
712-04294 |
Nut, M10, Gb/T6172.2 Price: $3.24 |
| 32 |
917-04917 |
GEAR-41MM This part replaces 717-04917. Price: $8.34 |
| 33 |
787-01976 |
Support, 19 x 10 x 5 Price: $3.82 |
| 34 |
736-04570 |
Washer, 34 x 15.5 x 1 Not Available Price: |
| 35 |
741-04514 |
Bearing, 6002z Price: $5.32 |
| 36 |
942-04362 |
Blade, Roller, TB R16 This part replaces 742-04362. Price: $98.75 |
| 36 |
942-04363 |
ROLLER BLADE Not Available This part replaces 742-04363. Price: |
| 37 |
787-01977 |
Shield, Deflector, TBR16 Price: $51.75 |
| 37 |
787-01979 |
Shield, Deflector, TBR18 Price: $61.60 |
| 38 |
787-01981 |
Bracket, Support, RH Price: $24.63 |
| 39 |
711-05536 |
Axle, Wheel, 19x65.5 Price: $7.71 |
| 40 |
712-04295 |
Nut, M8, Gb/T6170 Price: $3.14 |
| 41 |
710-05326 |
Bolt, M8x16gb/T5781 Price: $3.24 |
| 42 |
787-01985 |
Bracket, Adjustment, 9 Tooth RH Price: $6.07 |
| 42 |
787-01994 |
Bracket, Adjustment, 9 Tooth LH Price: $6.07 |
| 43 |
787-01987 |
Bracket, Rear, RH Price: $15.20 |
| 44 |
710-05327 |
Bolt, M6x10 Gb/T5780 Price: $3.49 |
| 45 |
764-04132 |
Grass Bag, TBR18 Price: $59.17 |
| 46 |
927-04374 |
STRAP-GRASSBAG REEL MOWER SUMEC This part replaces 727-04374. Price: $4.73 |
