| Ref | Part Number | Description |
|---|
| 1 |
144393 |
DECK.WELD.42. Price: Call Us |
| 1 |
703-1061 |
COUPLING ASSEMBLY-DRIVEN Not Available Price: |
| 2 |
715-3011 |
SPRING PIN1/4X 7/8 HVY Not Available Price: |
| 2 |
72140506 |
BOLT Price: Call Us |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
721-3019A |
GASKET Not Available This part replaces 721-3019. Price: |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 4 |
717-3020 |
COLLAR-SHIFTER Not Available Price: |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 5 |
717-3226 |
HOUSING, CREEPER Not Available Price: |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
723-3021 |
Breather Price: $20.30 |
| 7 |
727-3030 |
Wire, .062 Dia X 4.0 Lg Price: Call Us |
| 8 |
715-0248 |
SPRING PIN Not Available Price: |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
703-0409 |
YOKE-SHIFT Not Available Price: |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
932-05125 |
DETENT SHAFT SPRING This part replaces 732-0863. Price: $3.66 |
| 11 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
710-0421 |
SCREW-SET 5/16-18 x .25 CUP Not Available Price: |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
715-3034 |
ROLL PIN Not Available Price: |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
711-3213 |
SHIFT LEVER Not Available Price: |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
703-1094 |
PLATE-DETENT Not Available Price: |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
721-3008 |
O-RING-3/8 x 1/2 x 1/16 Not Available Price: |
| 17 |
72110610 |
BOLT RDHD 3/8-16 Price: Call Us |
| 17 |
936-0117 |
Washer, Flat, .385 x .620 x .033 This part replaces 736-0117. Price: $6.20 |
| 18 |
714-3010 |
Pin, Cotter, 3/32 Dia X 5/8 Lg Price: $4.08 |
| 18 |
72140505 |
BOLT Price: Call Us |
| 19 |
00012118 |
BLACK SHIFT KNOB Not Available This part replaces 720-3008. Price: |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
717-3230 |
RACE, PLANETARY Not Available Price: |
| 21 |
711-3074 |
SHAFT-DR INPUT Not Available Price: |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
717-3019 |
COUPLING-DIRECTOR Not Available Price: |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
717-3242 |
CARRIER ASSY, PLANET Not Available Price: |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
717-3022 |
GEAR-PLANET Not Available Price: |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
716-3006 |
SNAP RING Not Available Price: |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
717-3246 |
PLATE ASSEMBLY-FR Not Available Price: |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
941-0155 |
Bearing This part replaces 741-0155. Price: $22.09 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
750-3047 |
SPACER Not Available Price: |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
721-0193 |
Seal, Oil Price: Call Us |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 30 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 31 |
129963 |
WASHER Price: Call Us |
| 31 |
710-0615 |
SCREW 3/8-16 x 5.0 Not Available Price: |
| 32 |
129861 |
SUB= 153535 Price: Call Us |
| 32 |
710-0693 |
Screw, Hex Cap, 3/8-16 X 4.5 Lg Price: $12.87 |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 34 |
72110614 |
BOLT Price: Call Us |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 37 |
19131316 |
WASHER Price: Call Us |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 41 |
133551 |
PIVOT ROD Price: Call Us |
| 43 |
140083 |
ROD CLUTCH W/NIBS Price: Call Us |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 45 |
4497H |
RETAINER M Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 48 |
133944 |
HARD SMALL WASHER Price: Call Us |
| 49 |
133940 |
SUB= 151785 Price: Call Us |
| 50 |
131340 |
SHOULDER BOLT Price: Call Us |
| 51 |
69180 |
LOCKNUT Price: Call Us |
| 52 |
139888 |
BOLT.SHLD.5/16-18 Price: Call Us |
| 53 |
131845 |
BRAKE PAD ARM ASM Price: Call Us |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 55 |
140084 |
SUB= 151785 Price: Call Us |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 58 |
140086 |
SPRING TORSN BRAK Price: Call Us |
| 59 |
141043 |
GUARD IDLER TUV Price: Call Us |
| 67 |
106279X |
CONTROL KNOB LT Price: Call Us |
| 68 |
144200 |
BELT.V.T-PATH Price: Call Us |
| 71 |
142427 |
ROD CLUTCH 38/42 Price: Call Us |
| 72 |
131870 |
RETURN SPRING Price: Call Us |
| 73 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 74 |
121748X |
WASHER Price: Call Us |
| 75 |
12000029 |
RING Price: Call Us |
| 76 |
128903 |
SHOULDER BOLT Price: Call Us |
| 77 |
127845 |
SPRING KEEPER Price: Call Us |
| 78 |
140179 |
LEVER ASM CLT PRM Price: Call Us |
| 79 |
127498 |
BUSHING Price: Call Us |
| 80 |
128759 |
SUB= 918128759 Price: Call Us |
| 81 |
73350600 |
NUT Price: Call Us |
| 82 |
142028 |
TRUNION ADJ Price: Call Us |
| 83 |
120958X |
WASHER Price: Call Us |
| 84 |
144394 |
SUB= 156084 Price: Call Us |
| 85 |
72140620 |
BOLT Price: Call Us |
| 90 |
74760616 |
BOLT Price: Call Us |
| 91 |
132274 |
SUB= 532132274 Price: Call Us |
| 92 |
73800600 |
NUT Price: Call Us |
| 93 |
19171416 |
WASHER Price: Call Us |
| 94 |
132264 |
SUB= 532132264 Price: Call Us |
| 95 |
132273 |
SUB= 532132273 Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
