| Ref | Part Number | Description |
|---|
| 1 |
539109660 |
DRAW LATCH Price: $13.99 |
| 1 |
93-5333 |
ROD-CONTROL Price: $48.60 |
| 2 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 2 |
539110740 |
RIVET, BLIND, 5/32 DIA Price: $2.99 |
| 3 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 3 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 4 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 4 |
539105744 |
DECAL, BELT DRIVE Price: $5.99 |
| 5 |
3220-3 |
NUT-HJ Price: $0.28 |
| 5 |
539111270 |
PIN Price: $7.99 |
| 6 |
539111240 |
BLOWER DECK PLATE WLDMNT, 61" Price: $399.99 |
| 6 |
93-5552 |
DISCONTINUED Price: Call Us |
| 7 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 8 |
539111274 |
BELT SHIELD ASSY 61" Price: $179.99 |
| 8 |
93-5326 |
DISCONTINUED Price: Call Us |
| 9 |
539112138 |
HCS, 7/16-20 X 2 1/2, GR8 Price: $32.99 |
| 9 |
93-5262 |
SPRING-EXTENSION Price: $10.21 |
| 10 |
33114-020 |
SCREW-HH Price: $0.28 |
| 10 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 11 |
539102563 |
LANYARD Price: $7.99 |
| 11 |
93-5456-03 |
RH PEDAL ASM Price: $36.13 |
| 12 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 12 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 12 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7580. Price: $27.95 |
| 13 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 13 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 14 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 14 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 14 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 15 |
539111307 |
BELT Price: $22.99 |
| 15 |
93-5455-03 |
LH PEDAL ASM Price: $37.04 |
| 16 |
33114-025 |
SCREW-HH Price: $0.70 |
| 17 |
93-5313 |
BUSHING-NYLON Price: $16.84 |
| 18 |
32120-72 |
RING-SNAP Price: $2.09 |
| 19 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 20 |
322-4 |
SCREW-HH Price: $0.35 |
| 21 |
3218-2 |
NUT-JAM Price: $0.25 |
| 22 |
93-5568 |
ARM-LOCK Price: $17.77 |
| 23 |
93-5280-03 |
ARM-BRAKE, LH ASM Price: $80.29 |
| 24 |
93-4849 |
BEARING-BLOCK, PILLOW Price: $24.13 |
| 25 |
93-5473-03 |
LEVER-BRAKE, LH ASM Price: $102.67 |
| 26 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 28 |
32151-83 |
RING-SNAP Price: $0.34 |
| 29 |
93-5551 |
CLEVIS Price: $85.05 |
| 30 |
93-5475-03 |
BRAKE LATCH ASM Price: $132.94 |
| 31 |
93-5284-03 |
ARM-BRAKE, RH ASM Price: $80.29 |
| 32 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 33 |
93-5474-03 |
LEVER-BRAKE, RH ASM Price: $71.18 |
