| Ref | Part Number | Description |
|---|
| 1 |
539130393 |
FUEL CAP, HTC Price: $19.99 |
| 1 |
58-9580-03 |
REST-FOOT Price: $291.45 |
| 1 |
MA-F1550110025 |
BOLT,W/SPRING WASH Not Available Price: |
| 2 |
539130374 |
FENDER, LT Price: $74.99 |
| 2 |
60-0640-01 |
PEDAL-TRACTION Price: $172.47 |
| 2 |
MA-31A66-13200 |
GLOW PLUG This part replaces MA-31A66-03200. Price: $80.48 |
| 3 |
539130375 |
RP.FENDER, RT Price: $44.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 3 |
MA-31A66-04101 |
PLATE-CONTACT Not Available Price: |
| 4 |
539110252 |
FUEL TANK Price: $74.99 |
| 4 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 4 |
MA-MD001521 |
WASHER Not Available Price: |
| 5 |
532139277 |
STEM FUEL TANK This part replaces 539110432. Price: $6.99 |
| 5 |
60-2110 |
PIN Price: $1.42 |
| 5 |
MA-MF140026 |
BOLT Not Available Price: |
| 6 |
48-6790 |
BEARING Price: $12.14 |
| 6 |
576179401 |
HOUR METER This part replaces 539110074. Price: $27.99 |
| 6 |
MA-A3030110002 |
NUT Not Available Price: |
| 7 |
33014-00 |
NUT-HEX Price: $0.25 |
| 7 |
539102759 |
INSULATOR Price: $3.99 |
| 7 |
MA-A3600101002 |
WASHER,SPRING Not Available This part replaces MA-MF450406. Price: |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
522730101 |
CABLE, THROTTLE Price: $24.99 |
| 8 |
MA-03500141022 |
WASHER Not Available Price: |
| 9 |
3-2858 |
DISC-FRICTION Price: $31.32 |
| 9 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 9 |
MA-31A68-20300 |
BOLT-ALTERNATOR Not Available Price: |
| 10 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 10 |
60-1130 |
LEVER Price: $177.91 |
| 10 |
MA-31A68-02100 |
PLATE-ADJUSTING Not Available Price: |
| 11 |
3290-483 |
WASHER-CONICAL Price: $7.61 |
| 11 |
539113792 |
SWITCH, BRAKE 3P Price: $14.99 |
| 11 |
MA-30A66-00100 |
GASKET Not Available Price: |
| 12 |
325-9 |
SCREW-HH Price: $1.87 |
| 12 |
539110305 |
PLATE.CONTROL.CONSOLE.BLACK Price: $27.99 |
| 12 |
MA-MM43128202 |
RELAY-GLOW PLUG This part replaces MA-MM43128201. Price: $121.34 |
| 13 |
47-7030 |
BUSHING-RUBBER Price: $31.76 |
| 13 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 14 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 15 |
539131209 |
BATTERY TIE DOWN ASSEMBLY Price: $27.99 |
| 16 |
3217-9 |
NUT-HH Price: $0.37 |
| 16 |
539116400 |
TERMINAL COVER-SM Price: $2.99 |
| 17 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 18 |
33114-035 |
SCREW-HH This part replaces 48-7740. Price: $3.77 |
| 18 |
539101714 |
SOLENOID Price: $22.99 |
| 19 |
48-7100 |
DAMPER-STEERING Price: $441.57 |
| 19 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 20 |
3219-5 |
NUT-HEX Price: $1.22 |
| 20 |
539110077 |
DECAL, IGNITION CONSOLE Price: $2.99 |
| 21 |
58-4310 |
COLLAR-PINNED Price: $51.49 |
| 21 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 22 |
58-5100 |
WASHER-TRACTION Price: $28.50 |
| 22 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 23 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 23 |
60-5700 |
SPRING Price: $27.02 |
| 24 |
58-9010 |
TAB-CLAMP Price: $60.87 |
| 24 |
596917001 |
Screws This part replaces 539110673. Price: $2.99 |
| 25 |
3274-89 |
SCREW-HSH Price: $8.07 |
| 25 |
596789701 |
Screws This part replaces 539111229. Price: $1.99 |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 26 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 27 |
3250-40 |
SCREW-SPH Price: $0.54 |
| 27 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 28 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 28 |
98-1209-03 |
LEVER-PUMP Price: $336.56 |
| 29 |
539110457 |
LEFT HEADLIGHT LENS This part replaces 539110056. Price: $4.99 |
| 29 |
60-6990 |
WASHER Price: $4.62 |
| 30 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 30 |
539110455 |
LEFT HEADLIGHT RIM GREY Price: $4.99 |
| 31 |
3217-29 |
NUT-HEX Price: $0.25 |
| 31 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 32 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 32 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 33 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 33 |
532140401 |
KEY MLD GEN DELTA This part replaces 539107544. Price: $5.99 |
| 34 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
112-6500-01 |
BRACKET-LOCK, NEUTRAL This part replaces 60-0730-01. Price: $300.58 |
| 36 |
92-9228-03 |
LEVER Price: $170.54 |
| 37 |
3296-19 |
NUT-HEX Price: $0.65 |
| 38 |
60-6740 |
WASHER Price: $2.31 |
| 39 |
92-9221 |
CABLE ASM Price: $19.69 |
| 40 |
92-4730-03 |
PLATE-FLOOR Price: $1,213.65 |
| 42 |
60-0760 |
CLEVIS-ROD, TRACTION Price: $42.76 |
| 43 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 44 |
33114-020 |
SCREW-HH This part replaces 66-3160. Price: $0.28 |
| 45 |
58-0400-01 |
SHROUD Price: $472.86 |
| 46 |
62-7400 |
DECAL Price: $24.54 |
| 47 |
60-0600-03 |
BRACKET-PIVOT Price: $236.10 |
| 48 |
60-1110 |
BUSHING Price: $15.95 |
| 49 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 50 |
325-7 |
SCREW-HH Price: $1.53 |
| 51 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 52 |
2411-44 |
END-ROD Price: $72.59 |
| 54 |
76-3430 |
ROD-TRACTION Price: $79.20 |
| 55 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 65 |
322-6 |
SCREW-HH Price: $0.45 |
| 66 |
3218-2 |
NUT-JAM Price: $0.25 |
| 67 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 68 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 69 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 70 |
32128-20 |
NUT-HF Price: $0.99 |
| 71 |
33114-045 |
SCREW-HH Price: $0.68 |
| 72 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 73 |
3290-482 |
WASHER-BELLEVILLE Price: $5.87 |
| 539110451 |
RT |
HEADLIGHT RIM GREY Price: $4.99 539110451 |
| 539110453 |
RT |
HEADLIGHT LENS This part replaces 539110057. Price: $4.99 539110453 |
