| Ref | Part Number | Description |
|---|
| 1 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 1 |
532144393 |
Deck Asm MWR 42"weldment (AYP part number) Price: $139.99 |
| 2 |
3219-14 |
NUT-HEX Price: $0.25 |
| 2 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 3 |
532138017 |
BRKT ASM SWAY BAR Price: $7.99 |
| 4 |
3217-29 |
NUT-HEX Price: $0.25 |
| 4 |
532138440 |
BRKT DECK SW BAR Price: $3.99 |
| 5 |
18-1390 |
DISCONTINUED Price: Call Us |
| 5 |
532085902 |
RETAINER SPRING This part replaces 532004939. Price: $1.99 |
| 6 |
28-1030 |
DISCONTINUED Price: Call Us |
| 6 |
532178024 |
BAR SWAY DECK This part replaces 532130832. Price: $5.99 |
| 7 |
18-2670 |
DISCONTINUED X-REF Price: Call Us |
| 8 |
19-2930 |
DISCONTINUED Price: Call Us |
| 8 |
532850857 |
BLADE BOLT Price: $1.99 |
| 9 |
2410-13 |
DISCONTINUED Price: Call Us |
| 9 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 10 |
532140296 |
WASHER.BLADE Price: $2.99 |
| 11 |
3220-3 |
NUT-HJ Price: $0.28 |
| 11 |
532131323 |
Price: $12.85 |
| 12 |
37-9890 |
DISCONTINUED Price: Call Us |
| 12 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $6.99 |
| 13 |
39-3680 |
DISCONTINUED Price: Call Us |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $17.99 |
| 14 |
12-8140 |
KEY SWITCH Price: $39.86 |
| 14 |
532128774 |
HSG MANDREL Price: $22.99 |
| 15 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532128961. Price: $3.99 |
| 16 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 17 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 17 |
872110618 |
BOLT CARRIAGE Price: $2.99 |
| 18 |
38-1630 |
OIL PRESSURE GAGE Price: $307.03 |
| 18 |
872140505 |
BOLT This part replaces 532066238. Price: $2.99 |
| 19 |
38-1640 |
WATER TEMP GAGE Price: $202.86 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $2.99 |
| 20 |
18-2230 |
DISCONTINUED X-REF Price: Call Us |
| 20 |
532159770 |
BAFFLE.VORTEX This part replaces 532136888. Price: $12.99 |
| 21 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
38-1650 |
FUEL GAUGE Price: $185.83 |
| 22 |
532134753 |
Stiffener Bracket 42" deck (AYP part number) Price: $5.99 |
| 23 |
38-1670 |
MTNG BRKT W/38-1660 Price: $16.06 |
| 23 |
532177563 |
BRKT, DEFL. MOWER This part replaces 532131267. Price: $2.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $3.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK Price: $22.99 |
| 28 |
819111016 |
WASHER Price: $5.99 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $1.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $4.99 |
| 34 |
872110622 |
BOLT Price: $0.99 |
| 35 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 36 |
532173438 |
PULLEY.IDLER.FLAT This part replaces 532104360. Price: $14.99 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
532132823 |
IDLER SPRING SPACER Price: $4.99 |
| 40 |
873680600 |
LOCKNUT Price: $1.99 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK This part replaces 532134236. Price: $14.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 54 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 55 |
532151785 |
CAM ROLLER KIT This part replaces 532140084. Price: $27.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 61 |
532131950 |
SPRING EXTENSION Price: $4.99 |
| 68 |
532144200 |
V-BELT TRIPATH Price: $32.99 |
| 83 |
532120958 |
WASHER Price: $4.99 |
| 84 |
532156084 |
KEEPER.BELT.IDLER Price: $3.99 |
| 85 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $2.99 |
| 90 |
874780616 |
BOLT This part replaces 874760614. Price: $3.99 |
| 91 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $3.99 |
| 92 |
873680600 |
LOCKNUT This part replaces 532062336. Price: $1.99 |
| 93 |
819171416 |
WASHER Price: $2.99 |
| 94 |
539132264 |
MANUAL, OPERATOR Price: $3.20 |
| 95 |
532175747 |
BRACKET ASM, ROLLER This part replaces 532132273. Price: $7.99 |
| 111 |
532155197 |
BRACKET WHEEL GAUGE LH 42" DK Price: $11.99 |
| 112 |
532155198 |
BRACKET WHEEL GAUGE RH 42" DK Price: $11.99 |
| 113 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 114 |
873310500 |
NUT Price: $3.99 |
| 115 |
872110505 |
BOLT This part replaces 872110504. Price: $3.99 |
| 116 |
532004898 |
BOLT Price: $1.99 |
| 117 |
532105455 |
GUAGE WHEEL GT Price: $11.99 |
| 118 |
873680600 |
LOCKNUT This part replaces 532005394. Price: $1.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 120 |
819171512 |
WASHER Price: $3.99 |
| 121 |
532143723 |
BRACKET.EXTRUDED.GAGE.WHEEL Price: $7.99 |
| 125 |
TBD |
Price: Call Us |
| 128 |
532153390 |
WASHER FELT Price: $2.99 |
| 132 |
819132203 |
WASHER GT Price: $3.99 |
| 532130794 |
MANDREL |
ASM, LH 5PT STAR Price: $32.99 532130794 |
