| Ref | Part Number | Description |
|---|
| 1 |
132-5865 |
CANISTER-CARBON This part replaces 114-0289. Price: $80.55 |
| 1 |
532140779 |
PULLEY.V-GROOVE Price: $24.99 |
| 2 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 3 |
117-8399 |
STRAP-MOUNTING Price: $34.40 |
| 3 |
532140607 |
TRANSAXLE.HYDRO.319-0500.LR Price: $556.99 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
110-3254 |
HOSE-FUEL Price: $18.55 |
| 5 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 6 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 6 |
68-3630 |
HOSE-FUEL Price: Call Us |
| 7 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 8 |
2412-80 |
CLAMP-HOSE Price: $4.39 |
| 9 |
133-8499 |
VALVE-CHECK, VACUUM This part replaces 115-7868. Price: $14.10 |
| 9 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $5.99 |
| 10 |
115-7871 |
HOSE-FUEL Price: $5.23 |
| 10 |
532121749 |
WASHER Price: $2.99 |
| 11 |
119-2965 |
STRAP-TANK Price: $32.35 |
| 11 |
532123583 |
SQUARE KEY Price: $3.99 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 13 |
532140778 |
FAN.TRANSMISSION.HYDRO.6" Price: $5.99 |
| 14 |
120-5908 |
CABLE-BATTERY, NEGATIVE Price: $45.22 |
| 14 |
532009204 |
NUT STD Price: $2.38 |
| 15 |
112-6808 |
CABLE-BATTERY, POSITIVE Price: $70.12 |
| 16 |
106-5190 |
BATTERY Price: $170.85 |
| 16 |
532140763 |
SUPPORT, SHIFT HANDLE Price: $2.42 |
| 17 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 17 |
532140767 |
LINK, SHIFT Price: $2.64 |
| 18 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 19 |
109-1395 |
HOSE-FUEL Price: $15.64 |
| 20 |
115-9047 |
FUEL TANK ASM Price: $700.56 |
| 21 |
33114-016 |
SCREW-HH Price: $0.27 |
| 21 |
532140773 |
LEVER, SHIFT Price: $2.99 |
| 22 |
104-7102 |
PAD-BATTERY Price: $3.53 |
| 23 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $8.99 |
| 24 |
3339-175 |
STRAPPING-WEB This part replaces 94-1445. Price: $18.99 |
| 24 |
532140765 |
ROD, SHIFTER Price: $27.99 |
| 25 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 25 |
93-7968 |
PAD-FOAM Price: $33.52 |
| 26 |
119-6807 |
DECAL-WARNING Price: $7.37 |
| 27 |
532142564 |
LINE FUEL HYD 4" Price: $3.99 |
| 28 |
532140772 |
SPRING, TORSION Price: $19.99 |
| 30 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 31 |
532121199 |
SPACER SPLIT Price: $3.12 |
| 32 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 34 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 35 |
812000001 |
E-RING LT Price: $3.99 |
| 36 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 38 |
874760540 |
Bolt, Hex, Fin. 5/16 x 18 UNC x 2-1/2 Price: $2.99 |
| 39 |
819171912 |
WASHER Price: $3.99 |
| 40 |
596582201 |
Bolts This part replaces 874760524. Price: $2.99 |
| 41 |
819212013 |
Washer 21/32 x 1-1/4 x 13 Ga. Price: $2.99 |
| 42 |
532140769 |
PIN Price: $2.38 |
| 43 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 44 |
532156047 |
PIVOT SHAFT This part replaces 532140764. Price: $11.51 |
| 45 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 46 |
532142578 |
VENT CAP 70109 This part replaces 532142917. Price: $37.99 |
| 47 |
532142918 |
O-RING KIT 70110 Price: $22.99 |
| 48 |
532140912 |
ACTUACTOR Price: $8.60 |
| 49 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
