| Ref | Part Number | Description |
|---|
| 1 |
94-3145 |
SCREW-PULLEY Price: $9.84 |
| 2 |
74-8080 |
WASHER This part replaces 94-3146. Price: $4.77 |
| 2 |
921-3004 |
GASKET This part replaces 721-3004. Price: $9.36 |
| 3 |
923-3014 |
Filter, Oil This part replaces 723-3014. Price: $18.90 |
| 3 |
94-3144 |
PULLEY-CRANKSHAFT Price: $766.47 |
| 4 |
721-3005 |
O-RING Not Available Price: |
| 4 |
74-8100 |
GEAR-PINION Price: $58.79 |
| 5 |
727-3009 |
CONNECTOR-37 DEGREE-7/8-14 Not Available Price: |
| 5 |
98-3833 |
GEAR - OIL PUMP This part replaces 74-8110. Price: $26.24 |
| 6 |
727-3027 |
TUBE ASSEMBLY Not Available Price: |
| 6 |
74-8120 |
KEY-WOODRUFF Price: $3.36 |
| 7 |
710-3212 |
SCREW 1/4-20 x 2 Not Available Price: |
| 7 |
94-3150 |
SCREW-HH Price: $1.50 |
| 8 |
74-7560 |
LOCKWASHER This part replaces 94-3151. Price: $0.67 |
| 8 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 9 |
74-8140 |
COVER Price: $137.43 |
| 9 |
748-3038 |
ADAPTER-PUMP Not Available Price: |
| 10 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 10 |
74-8150 |
GASKET-COVER Price: $4.08 |
| 11 |
710-3220 |
Bolt, Hex Patch, 1/4-20 x 1.0 Lg GR5 Price: $3.21 |
| 11 |
94-3148 |
SEAL Price: $33.41 |
| 12 |
74-8170 |
BEARING SET (STD) Price: $208.01 |
| 12 |
748-3030A |
DRIVE COUPLING Not Available Price: |
| 13 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 13 |
94-3141 |
DISCONTINUED Price: Call Us |
| 14 |
74-8230 |
SHAFT-CRANK Price: $3,552.00 |
| 14 |
948-3044 |
DRIVE HUB Not Available This part replaces 748-3044. Price: |
| 15 |
721-3025 |
O-RING 2.489 ID x .070 Not Available Price: |
| 15 |
94-3147 |
DISCONTINUED Price: Call Us |
| 16 |
735-3029 |
COUPLING BOOT Not Available Price: |
| 16 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 17 |
916-0171 |
RETAINING RING This part replaces 716-0171. Price: $5.04 |
| 17 |
94-3149 |
GEAR-FLYWHEEL Price: $113.49 |
| 18 |
736-0463 |
Washer, Flat, .25 x .62 x .052 Thk Price: $3.91 |
| 18 |
74-8270 |
DISCONTINUED Price: Call Us |
| 19 |
74-8280 |
SCREW-HH Price: $4.63 |
| 20 |
738-3099 |
DRIVE SHAFT 26.15 Not Available Price: |
| 20 |
74-8290 |
DISCONTINUED Price: Call Us |
| 21 |
710-3211 |
Screw, Socket Hd Cap, 1/4-20 x 1.75 Lg Price: $4.52 |
| 21 |
74-8300 |
CLIP-PIN, PISTON Price: $2.96 |
| 22 |
74-8310 |
PIN-PISTON Price: $24.33 |
| 22 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 23 |
748-3037 |
FAN NUT 1/4-20 Not Available Price: |
| 23 |
94-3158 |
PISTON RING SET Price: $233.60 |
| 24 |
710-3258 |
HEX SCREW PATCH-M8X1.25X50MM Not Available Price: |
| 24 |
98-9965 |
DISCONTINUED This part replaces 94-3154. Price: Call Us |
| 25 |
74-8360 |
CONNECTING ROD This part replaces 94-3153. Price: $1,118.95 |
| 25 |
936-3008 |
Washer, Flat, .344 x .750 x .120 This part replaces 736-3008. Price: $6.24 |
| 26 |
KH-24-029-12-S |
DRIVE SHAFT ADAPTER This part replaces 719-3096. Price: $32.02 |
| 27 |
74-8380 |
DISCONTINUED Price: Call Us |
| 28 |
74-8400 |
BOLT-ROD, CONNECTING This part replaces 94-3156. Price: $23.09 |
| 29 |
74-8420 |
PISTON SET Price: $3,551.52 |
| 29 |
94-3157 |
PISTON SET Price: $3,570.53 |
| 33 |
94-3152 |
SCREW-HH Price: $2.62 |
| 539101080 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 539101768 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 539101771 |
539101771 |
FUSE, 7.5 AMP 32 VOLT ATO Price: $3.99 |
| 539102086 |
539102086 |
FUSE, 20 AMP 32 VOLT ATO Price: $5.99 |
| 539102436 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 539102587 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 539102617 |
539102617 |
SCREW, #1--24 X 1/2 SLOTTED Price: $2.99 |
| 539102678 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 539102758 |
539102758 |
CABLE-NEGATIVE Price: $12.99 |
| 539102759 |
539102759 |
INSULATOR Price: $3.99 |
| 539102914 |
539102914 |
RELAY Price: $21.99 |
| 539104974 |
539104974 |
POST.CABLE LONG Price: $27.99 |
| 539105169 |
539105169 |
KNOB Price: $7.99 |
| 539105728 |
539105728 |
BATTERY HOLD DOWN Price: $27.99 |
| 539107541 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 539107544 |
532140401 |
KEY MLD GEN DELTA This part replaces 539107544. Price: $5.99 |
| 539110074 |
576179401 |
HOUR METER This part replaces 539110074. Price: $27.99 |
| 539110950 |
539110950 |
FRAME HARNESS Price: $279.99 |
| 539976934 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 539976952 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 539976977 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 539990717 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
