| Ref | Part Number | Description |
|---|
| 1 |
108-9083 |
PLATE-SIDE, RH Price: $328.36 |
| 1 |
823230506 |
SET SCREW Price: $2.99 |
| 2 |
108-9082 |
PLATE-SIDE, LH Price: $328.36 |
| 2 |
532130812 |
ENGINE PULLEY Price: $17.99 |
| 3 |
104-3396 |
SCREW-HH Price: $0.75 |
| 3 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 4 |
874770508 |
BOLT Price: $2.99 |
| 4 |
99-8662 |
TUBE-SPRING Price: $21.55 |
| 5 |
3218-5 |
NUT-JAM Price: $0.27 |
| 5 |
817490440 |
BOLT, THD ROLLER 1/4-20 X 2-1/ Price: $2.99 |
| 6 |
583753101 |
SHIELD.INNER.FRT.PNT This part replaces 532446250. Price: $32.99 |
| 6 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
532139155 |
SPACER.SPLIT Price: $2.99 |
| 9 |
110-4079 |
SPRING-COMPRESSION Price: $13.57 |
| 9 |
532432928 |
GUARD, BELT Price: $22.99 |
| 10 |
532109227 |
PAD IDLER TI Price: $2.99 |
| 11 |
532009484 |
CONDUIT CLIP T This part replaces 532446045. Price: $3.99 |
| 12 |
110-4069 |
BRACKET Price: $5.57 |
| 12 |
532009180 |
V BELT STD Price: $19.99 |
| 13 |
115-2007 |
ROD-SPRING Price: $34.97 |
| 13 |
812000028 |
RETAINING RING LT Price: $4.99 |
| 14 |
532151223 |
SHEAVE.TRANS Price: $22.99 |
| 14 |
92-2762 |
PIN-HAIR Price: $1.09 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 16 |
812000036 |
KLIP RING TI Price: $3.99 |
| 17 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 17 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 18 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 18 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $17.99 |
| 19 |
107-3258 |
FRAME Price: $331.61 |
| 19 |
580530002 |
ARM.ASM.IDLER.PNT Price: $8.99 |
| 20 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 20 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 21 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 21 |
532106968 |
SHAFT.IDLER.TILLER Price: $11.99 |
| 22 |
67-9410 |
WASHER Price: $2.04 |
| 23 |
108-4279 |
SPACER-FRAME Price: $8.34 |
| 24 |
108-4284 |
TUBE-SUPPORT Price: $60.29 |
| 25 |
110-9713 |
CARRIER FRAME ASM Price: $642.24 |
| 25 |
873220500 |
NUT This part replaces 873350500. Price: $3.99 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
323-7 |
SCREW-HH Price: $0.65 |
| 28 |
114-3972 |
CHAIN Price: $8.62 |
| 29 |
112-6564 |
BRACKET-CHAIN Price: $47.71 |
