| Ref | Part Number | Description |
|---|
| 1 |
144393 |
DECK.WELD.42. Price: Call Us |
| 1 |
49-6200-01 |
LEVER-CUTTING Price: $100.17 |
| 2 |
283-61 |
PIN-YOKE Price: $1.56 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
282-2 |
YOKE Price: $30.04 |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 4 |
3220-2 |
NUT-JAM Price: $0.50 |
| 5 |
49-5430 |
ROD-CONTROL Price: $75.94 |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
49-6110-01 |
GUARD-ROD, TRANSMISSION Price: $65.82 |
| 7 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 8 |
100-9819 |
LATCH ASM Price: $127.30 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
100-9821 |
PLATE-SWITCH, REED Price: $20.58 |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
93-8062 |
DECAL-BRAKE, PARKING Price: $4.95 |
| 11 |
83-0640-01 |
PLATE-FOOTREST Price: $105.48 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
49-6120 |
PAD-FOOTREST Price: $33.37 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
32141-111 |
NUT-ADJUSTING Price: $6.09 |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
95-1629 |
HINGE-LOWER Price: $10.72 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
93-8075 |
DECAL-MOW/LIFT Price: $6.44 |
| 17 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 17 |
72110618 |
BOLT CARRIAGE Price: Call Us |
| 18 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 18 |
72140505 |
BOLT Price: Call Us |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 19 |
3274-31 |
SCREW-HSBH Price: $0.89 |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 21 |
321-4 |
SCREW-HH Price: $0.99 |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
83-0200-01 |
PLATE-COVER, LH Price: $46.92 |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
32128-33 |
NUT-HF Price: $0.25 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
93-9901-01 |
BRACKET-LOCKOUT, MOW Price: $92.00 |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
83-0080 |
SPRING-PIVOT, LIFT Price: $20.57 |
| 28 |
106-6396 |
LIFT-PIVOT V Price: $63.16 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
27-2270 |
ROD-ADJUSTMENT, BRAKE Price: $32.18 |
| 30 |
10-8100-01 |
STRAP-SHAFT, BRAKE Price: $34.17 |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 31 |
129963 |
WASHER Price: Call Us |
| 31 |
32121-35 |
PIN-ROLL Price: $0.79 |
| 32 |
153535 |
PULLEY.MANDREL.42 Price: Call Us |
| 32 |
88-9640-01 |
BRACKET-LIFT PIVOT, LH Price: $42.90 |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 33 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 34 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 34 |
72110622 |
BOLT Price: Call Us |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 35 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 36 |
93-7631 |
PAD-FOOT, LIFT Price: $8.10 |
| 37 |
106-6395 |
CUTTING CONTROL SHAFT ASM Price: $151.92 |
| 37 |
19131316 |
WASHER Price: Call Us |
| 38 |
132823 |
SUB= 532132823 Price: Call Us |
| 38 |
83-2590 |
BOLT-SHOULDER, PIVOT Price: $50.18 |
| 39 |
83-0160 |
SHAFT-BRAKE Price: $111.83 |
| 40 |
106-6394 |
MOW PEDAL ASM Price: $72.96 |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 41 |
93-7630 |
PAD-FOOT Price: $8.20 |
| 42 |
93-7629 |
PAD-FOOT, BRAKE Price: $25.13 |
| 43 |
88-9630-01 |
BRACKET-LIFT PIVOT, RH Price: $42.90 |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 44 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 45 |
321-11 |
SCREW-HH Price: $0.36 |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 46 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 47 |
69-9760 |
COVERPLATE Price: $5.38 |
| 48 |
56-7970 |
CLAMP-TUBE Price: $10.02 |
| 49 |
88-9620 |
DECAL Price: $26.60 |
| 50 |
10-8140 |
SPRING-LATCH, BRAKE Price: $18.38 |
| 51 |
321-3 |
SCREW-HH Price: $0.28 |
| 52 |
93-9898 |
DECAL-LOCK Price: $5.59 |
| 53 |
93-9903 |
PIN-MOW, LOCKOUT Price: $65.65 |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 54 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 55 |
155046 |
ARM-IDLER Price: Call Us |
| 55 |
27-2320 |
BEARING Price: $15.22 |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 56 |
3-1506 |
BUSHING Price: $2.42 |
| 57 |
76-0410 |
SPRING-COMPRESSION Price: $5.92 |
| 58 |
93-9904 |
ARM-MOW, LOCKOUT Price: $29.06 |
| 59 |
141043 |
GUARD IDLER TUV Price: Call Us |
| 59 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 60 |
80-7730 |
SPACER Price: $1.97 |
| 61 |
131950 |
SPRING.EXTENSION Price: Call Us |
| 65 |
104-2057 |
SENSOR Price: $136.35 |
| 66 |
33113-016 |
SCREW-HH This part replaces 48-7620. Price: $0.34 |
| 67 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 68 |
144200 |
BELT.V.T-PATH Price: Call Us |
| 68 |
33023-00 |
NUT-LOCK This part replaces 49-7810. Price: $0.25 |
| 83 |
120958X |
WASHER Price: Call Us |
| 85 |
72140618 |
BOLT RDHD 3/8-16 Price: Call Us |
| 111 |
155197 |
BRACKET.GWHL.LH. Price: Call Us |
| 112 |
155198 |
BRACKET.GWHL.RH. Price: Call Us |
| 113 |
17490512 |
SCREW Price: Call Us |
| 114 |
73510500 |
NUT Price: Call Us |
| 115 |
72110504 |
SUB= 872110504 Price: Call Us |
| 116 |
4898H |
BOLT M Price: Call Us |
| 117 |
105455X |
WHEEL.GAGE.BLK.PL Price: Call Us |
| 118 |
73930600 |
LOCKNUT Price: Call Us |
| 119 |
19121414 |
WASHER Price: Call Us |
| 120 |
19171512 |
WASHER Price: Call Us |
| 121 |
143723 |
BRACKET.EXTRD.GWL Price: Call Us |
| 125 |
76020816 |
COTTER PIN Price: Call Us |
| 128 |
153390 |
WASHER.FELT. Price: Call Us |
| 132 |
19132203 |
WASHER GT Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
