| Ref | Part Number | Description |
|---|
| 1 |
121-5896 |
BRUSH-SCRAPER, NARROW (21 INCH) Price: $126.35 |
| 1 |
583280801 |
SEAT.9"BLK.NO.LOGO.MILSCO This part replaces 532403017. Price: $129.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
115-7364 |
BLOCK-CLAMP, SCRAPER Price: $17.51 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 2 |
631767 |
SPRING This part replaces 632016. Price: $1.25 |
| 3 |
115-7372 |
SCREW-HH Price: $0.47 |
| 3 |
532140675 |
STRAP Price: $3.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 5A |
630738 |
SPRING Price: $1.25 |
| 5B |
630766 |
SPRING Price: $1.25 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 7 |
630973 |
SHAFT & LEV Price: $5.16 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 8 |
632045 |
SPRING Price: $1.25 |
| 9 |
631582 |
SHUTTER Price: $1.20 |
| 10 |
532441805 |
PAN.ASM.SEAT.SHORT.SLD.ADJ.TEX This part replaces 532199180. Price: $29.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
532199370 |
BRKT.MNT.OPC.SW.SEAT. Price: $2.99 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 19 |
532199372 |
KNOB.SEAT.ADJ. Price: $4.99 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 22 |
631583 |
POWER SCREW Price: $10.18 |
| 23 |
630740 |
O RING Price: $1.49 |
| 23A |
630740 |
O RING Price: $1.49 |
| 24 |
631838 |
ADJ SCREW This part replaces 631078. Price: $2.71 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 27 |
631184 |
WASHER Price: $1.25 |
| 27A |
631184 |
WASHER Price: $1.25 |
| 28 |
631972 |
WASHER Price: $1.25 |
| 29 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 29A |
631183 |
WASHER Price: $1.25 |
| 30 |
630739 |
WASHER Price: $1.25 |
| 30A |
630739 |
WASHER Price: $1.25 |
| 31 |
632527 |
FUEL FITTING Price: $6.03 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 42 |
532199371 |
WASHER.CUP.SEAT. Price: $2.99 |
