| Ref | Part Number | Description |
|---|
| 1 |
125046140 |
Lever (Incl. Ref. #2, 6 7) Price: Call Us |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
036800008 |
Circlip Price: Call Us |
| 4 |
026200010 |
Washer Price: Call Us |
| 5 |
125406071 |
Lever Price: Call Us |
| 9 |
198217220 |
Spring Price: Call Us |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
031100004 |
Pin Price: Call Us |
| 11 |
198217420 |
Spring Price: Call Us |
| 12 |
125156170 |
Arm Price: Call Us |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 13 |
052100070 |
O Ring Price: Call Us |
| 14 |
036800008 |
Circlip Price: Call Us |
| 15 |
125416020 |
Lever Price: Call Us |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 16 |
010110630 |
Screw Price: Call Us |
| 17 |
023100006 |
Nut Price: Call Us |
| 18 |
532441462 |
CAP.ASM.FUEL.2.25"TOP.TURN Price: $11.99 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
125116130 |
Shaft Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
052100030 |
O-Ring Price: Call Us |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
036800005 |
Circlip Price: Call Us |
| 24 |
125976120 |
Stay Price: Call Us |
| 25 |
011300618 |
Screw Price: Call Us |
| 26 |
010109264 |
Screw Price: Call Us |
| 27 |
023100006 |
Nut Price: Call Us |
| 28 |
125176080 |
Lever Price: Call Us |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
198216760 |
Spring Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
026200008 |
Washer Price: Call Us |
| 31 |
020300008 |
Nut Price: Call Us |
| 34 |
125156180 |
Arm Price: Call Us |
| 35 |
052100050 |
O Ring Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 This part replaces 532424765. Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 This part replaces 532424766. Price: $24.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
