| Ref | Part Number | Description |
|---|
| 0 |
632027 |
SERVICE CARB This part replaces 631983. Price: Call Us |
| 1 |
119-7481 |
NUT-FERRULE Price: $34.00 |
| 1 |
631776A |
SHAFT & LEV This part replaces 631776. Price: $12.00 |
| 2 |
119-7480 |
FERRULE Price: $2.64 |
| 2 |
530015241 |
Screw Price: $1.99 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 3 |
119-7457 |
NUT Price: $6.92 |
| 3 |
525592801 |
Assy - Muffler This part replaces 545081845. Price: $22.99 |
| 4 |
119-7545 |
FITTING-BULKHEAD Price: $43.77 |
| 4 |
530058982 |
Bolt Price: $1.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
127-2638 |
HOSE This part replaces 127-2328. Price: $48.11 |
| 5 |
545081832 |
Gasket-Muffler (gasket kit) Price: $11.99 |
| 5 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 6 |
127-2452 |
TUBING-CONVOLUTED, SLIT Price: $14.66 |
| 6 |
545115301 |
Cylinder Price: $27.99 |
| 6 |
631778 |
SHUTTER Price: $1.20 |
| 7 |
530015953 |
Bolt Price: $1.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 9 |
545084901 |
Adapter - Carb. Price: $9.99 |
| 10 |
32180-083 |
WEDGE Price: $1.85 |
| 10 |
530016441 |
Screw Price: $1.99 |
| 10 |
632740 |
SHAFT & LEV This part replaces 631812. Price: $4.26 |
| 11 |
32180-084 |
WEDGE Price: $1.01 |
| 11 |
545115501 |
Linkage - Throttle Price: $2.99 |
| 11 |
632043 |
SPRING Price: $1.25 |
| 12 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
127-2527 |
TUBING-CONVOLUTED, SLIT Price: $2.42 |
| 13 |
545157102 |
Lever- Choke (Gold) Price: $7.99 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
3256-69 |
WASHER-FLAT This part replaces 127-2360. Price: $0.62 |
| 14 |
545112602 |
Base - Airbox Price: $7.99 |
| 14 |
631753 |
SHUTTER Price: $1.25 |
| 15 |
127-2451 |
PLATE-CONNECTOR Price: $12.11 |
| 15 |
530016429 |
Screw Price: $1.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
545116801 |
Filter Price: $2.99 |
| 17 |
545112702 |
Cover - Air Box Filter Price: $5.99 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
530035497 |
Bulb - Purge (walbro 188-16) Price: $4.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
545081832 |
Gasket (Carb / Adapter) (gasket kit) Price: $11.99 |
| 20 |
545081832 |
O-Ring (Adapter / Cylinder) (gasket kit) Price: $11.99 |
| 20 |
630898 |
ADJ SCREW Price: $1.69 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
545154009 |
PISTON RING This part replaces 530012472. Price: $1.99 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
530015162 |
Retainer - Wrist Pin Price: $1.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
545156002 |
KIT PISTON CONN ROD FORGED This part replaces 545081865. Price: $14.99 |
| 25 |
545081826 |
Kit - Ignition Module This part replaces 545158001. Price: $32.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 26 |
530016357 |
Screw Price: $1.99 |
| 27 |
545127601 |
Assy - Wire Harness Price: $5.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
545081832 |
O-Ring (Cyl/Crankcase) (gasket kit) Price: $11.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
530015828 |
Washer Price: $1.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
545221701 |
FLYWHEEL ASSY This part replaces 530054115. Price: $8.99 |
| 30 |
631725 |
INLET NEEDLE Price: Call Us |
| 31 |
530015941 |
Retainer - Crankshaft Price: $1.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
530055728 |
Bearing - Outer Price: $6.99 |
| 33 |
530019264 |
Seal Price: $2.99 |
| 36 |
545102102 |
Assy - Crankcase & Crankshaft Price: $22.99 |
| 38 |
530057954 |
Assy - Rear Plug Price: $3.99 |
| 40 |
631583 |
POWER SCREW Price: $10.18 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
